MAIN CHARACTERISTICS

Builder: Cantieri di Pisa SRL (Italy)

Model: Cantieri di Pisa Custom 112?

Naval Architect: Cantieri di Pisa?

Exterior Designer: Acube Design

Interior Designer: Cantieri di Pisa / Acube Design / Antonio Luxardo (Optima)

Type: Motor Yacht / Superyacht / Flybridge Yacht / Raised Pilothouse

Hull Type: Planing

Hull Material: Aluminium Alloy

Superstructure Material: Aluminium Alloy

Decks: Teak-laid

Year: 2027 (New)

Overall Length: 33.90 m (111? 3?)

Waterline Length: 28.50 m (93? 6?)

Beam: 7.45 m (24? 5?)

Draft: 2.00 m (6? 7?)

Headroom: 2.10 m (6? 11?)

Displacement (light load): 103,000 kg (227,076 lb) approx.?

Displacement (full load): 121,000 kg (266,759 lb) approx.

Gross Tonnage: 130 GT

Class: RINA Commercial Yachts

Location: Pisa, Tuscany, Italy

?

PROPULSION

Type / Fuel: Twin Diesel

Main Engines: 2 x 2000 Hp MAN V12-2000 @ 2300 RPM

Maximum Speed: 27 knots

• Range @ 27 Knots: 580 NM

Cruise Speed: 23 knots

• Range @ 23 Knots: 760 NM

Economical Speed: 10 knots

• Range @ 10 Knots: 1450 NM

Transmissions: 2 x Shaft line drives in AQUAMET 17

Propellers: 2 x DETRA counter-rotating, skewed, 5-blade props.

Rudders: 2 x Rudders in AISI 316 L with an approx. surface of 1.5 m2

?

TANKAGE

Fuel Capacity: 16,000 l (4,227 US Gallons)

Fresh Water Capacity: 2,650 l (700 US Gallons)

Black Water Tank: 900 l (238 US Gallons)

Grey Water Tank: 900 l (238 US Gallons)

Clean Lube Oil: 200 l (53 US Gallons)

Sludge Oil: 200 l (53 US Gallons)

?

ACCOMMODATION

10 Guests in 5 en-suite staterooms

Guest Cabin Configuration:

• Full-beam Owner?s suite forward on main deck with office and walk-in dressing, vanity, lounge area with sofa, and en-suite bathroom with separate shower and bathtub compartments
• 2 x Double VIP cabins on lower deck each with closets, desks and en-suite bathroom
• 2 x Twin cabins on lower deck each with closets, desks and en-suite bathroom

Crew Accommodation:

• 5 Crew in 3 cabins
• Captain?s cabin
• 2 x Crew cabins
• All on lower deck forward and each with en-suite facilities

Open air flybridge with sunbeds, wetbar, dining area, lounging area, and exterior pilot station

State-of-the-art wheelhouse on raised pilothouse

Stern beach club with overlooking skylight, day head and optional sauna with shower

Aft cockpit with skylight, 2 x chaise longues, sofa with adjustable backrests and side tables

Forward deck with ample lounging area and 2 tables

Main deck with main saloon and formal dining with day head and direct access to fully equipped galley

Crew mess with dinette & laundry area forward on lower deck

?

MAIN EQUIPMENT

2 x CMC 1.6 m2 zero speed and underway electric fin stabilizers

CMC counter-rotating electric bow thruster 36 kW

Hydraulic power pack

Air conditioning throughout

RACOR filters for engines and generators

ALFA LAVAL MIB 303 oil separator

Compressed air system with 120 l mini compressor

Machine standard cooling system suitable for Mediterranean waters

Domestic water system

Fresh water purifier

Black and grey water system

Motorpump: MPFS 40/14, 6.2 kW

Firefighting Plant: 2 x Sea water pumps GIANNESCHI ACM 501 BT, 400V, 3-phase (the 2 pumps are interconnected and can be used alternatively for firefighting and bilge suction)

Bilge Plant: 2 x Pumps GIANNESCHI ACM 501/C, 400V, 3-phase

Fixed Firefighting Plant: Fixed gas NOVEC firefighting system fitted for the engine room

Fuel Transfer Pump: GIANNESCHI ACB 431/B, 400 V, 3-phase, 2.2 kW

Tender Fuelling Pump: GIANNESCHI PE 56 0.50 kW

Oil Change Plant: 2 x Pumps GIANNESCHI FQ 40, 400V, 3-phase (one for dirty oil and one for clean oil)

Engine Room and Garage Ventilation:?

• 2 x Ventilators GIANNESCHI ELL/AP 565/1, 400V, 3-phase, 2.2 kW?
• 2 x Extractors GIANNESCHI VCR 501/D, 400V, 3-phase, 2.2 kW

Sludge Evacuation System: HAMMAN treatment system which separates it and sludge tank included according to MARPOL and RINA Class recommendations

Wastewater Treatment Plant: HAMANN HL CONT PLUS COMPACT 0125

Vacuum Station (for toilets): JETS EDGE S DUO

Engine Exhaust System: Wet exhausts with through-hull outlet, according to engine manufacturer?s standards

Reverse osmosis fresh water maker (capacity of approximately 3,000 l per 24 hours)

?

ELECTRICAL EQUIPMENT

Electrical Circuits: 400V AC, 230V AC / 24V DC

90 KVA transformer, inlet 400V, 3-phase, outlet 400/230V, 3-phase + neutral

Service battery bank

Engine start battery bank

Generators start battery bank

Emergency battery bank

MASTERVOLT battery chargers

MASTERVOLT inverters

Generators: 2 x 50 kW KOHLER 50EFOZDJ, 3-phase @ 1500 RPM

?

ENTERTAINMENT EQUIPMENT

LCD TV with Skybox and Blu-ray driver in each cabin

LCD TV with Skybox and Blu-ray driver in main saloon with up/down mechanism

Main deck rack with 32 GB hard drive to have a huge storage of movies and music

Amplifier located also in the rack?

Speakers and subwoofers installed in suitable positions to provide best Dolby surround audio

?

DECK EQUIPMENT

2 x Vertical anchor windlasses 3500 W, reversible, in polished stainless steel

2 x Galvanized POSIDONIA High Holding Power (HHP) stainless steel anchors

2 x Galvanized 150 m stainless steel chains complete with end links, shackles, anchor swivels and quick release

Chain washing system

Motorized drum for shore power cable

2 x Stern mooring capstans 2500 W, reversible, polished stainless steel

Hydraulic stern platform / Opening beach club?

Rear garage door to port

Floodable lateral tender launching and recovery system

Electro-hydraulic operating garage watertight door, upward opening

SEABOBs storage (to starboard)

Hydraulic telescopic stern gangway (approximately 50/55cm wide x 5m long)

Automatic sliding door on main deck

800 kg gantry crane fitted on the garage ceiling

200 l Diesel gravity tank for tender fuelling with hose reel and flow-meter

?Pirate Searchlight? projector

Removable stainless-steel shower on the aft platform

Sun awnings with carbon poles on the aft deck, flybridge and foredeck

6 x CANTALUPI underwater lighting in white (2 on stern platform, 2 to port, 2 to starboard)

Stainless-steel vessel name, backlit in white, on sides (up to 8 characters per side)

Stainless-steel boat name, backlit in white, on the stern on the beach club door

Loose outdoor furniture excluded (MINOTTI optional)

BURMA teak decks 12 mm throughout

Hot/cold fresh water connections (all decks)

Compressed air intakes (stern deck, garage and bow deck)

Flybridge wetbar

Access to foredeck via opening hatch from raised pilothouse

Foredeck??Portuguese bridge? with settees and tables

Main deck Mini-fridge

Loose furniture to be selected by ROYAL BOTANIA or RODA catalogues

Hard top system to cover the deck external dining area

Set of SUNBRELLA covers for all exterior sofa and sun cushions supplied as standard equipment

Awning to protect the instrument panel of the outside side control wings and the filtering awning, transparent type, for frontal windows of the wheelhouse

Covers for all the capstans

Supply of mooring ropes, fenders and lifelines in accordance with RINA Class and Flag requirements

?

SAFETY & SECURITY EQUIPMENT

Supplied in accordance with RINA Class and Flag requirements

?

TENDERS & WATERSPORTS

Tender to be stored in the floodable garage with lateral launching system

Maximum size of the tender 4.50 m (14? 9?)?? Owner?s supply

2 x Jet-skis, SEABOBs and other PWC, kayaks, snorkelling gear, etc.?? Owner?s supply

?

ADDITIONAL OPTIONS

Please consult with us.

3 x Finishing proposals to select.

Available on request.

Completion in 12 Months from contract signature. Hull and superstructure ready with inventory supplied and pending to outfit.

At the shipyard, prior appointment please. Short notice possible.

5 Years on the hull, 1 year on the rest of the ship?s systems (commercial).

Berth place management possible on French or Italian Riviera as well as Spain (Mainland and Balearic Islands), Greece and Turkey.

These particulars are given in good faith as supplied to us but cannot be guaranteed and cannot be used for contracts.
