Hull length 11,90 mt. 39.0 ft

Length overall 12,05 mt. 39.53 ft

Beam 3,80 mt. 12.5 ft

Draft (max) 0,80 mt. 2.6 ft

Displacement (half load) 7.5 tons.

Engines N. 2 Mercury Verado 300 CV

Steering system Integrated Electro Hydraulic system

Fuel capacity 242 UK gallons (1100 Lt)

Maximum Theoretical Cruising Autonomy 3000 RPM ? 28 Knots = 300 Nautical Miles

Water Capacity 105,6 UK gallons (400 Lt)

Cruising speed 28 knots

Top speed 36 knots

Design: Nauta Design/Hydrotec

Certification CE ? B off shore

• Vessel built in accordance with CE certification, cat. B offshore.
• Sandwich in sides and bottom.
• GRP swimming platform with teak gratings. and folding swimming ladder
• Hinged transom door.
• Watertight bulkheads: bow - midship / storage room - stern.
• Electrical trim tabs model INTRUDER.
• Antifouling bottom and water level paint.
• Cathodic protection with sacrificial anodes.

• Deck and superstructure laminated in GRP sandwich with PVC core.
• White gelcoat finish with sprayed non-skid.
• N.2 cockpit sun beds on hatches and on foredeck.
• N.2 storage hatches.
• N.1 systems locker hatch and anchor locker.
• N. 4 handrails, on roof top and bow deck.

Teak

• Cockpit, helm station and dinette sole covered with 10 mm teak and solid side coamings.
• Solid teak sheer line toe rail.

Hatches, portlights and windows

• Low profile deck hatches with nets and blackout sheets.
• Custom smoke grey plexi windshield shatterproof.
• Windshield center section opening with upper hinges.
• N.2 wipers with freshwater washer. Pump connected to freshwater tank.
• Hatches handles and hinges in stainless steel.
• Electrically sliding pilothouse roof hatch.

Deck accessories

• Mooring and steaming light mast.
• Teak Flagpole.
• Watertight inlet for shore power.
• Hidden deck shower with hot and cold fresh water.
• Courtesy foot-lights.
• Inox Swimming ladder removable.

Mooring system

• Anchor windlass 1000 W with remote switches at helm and forepeak.
• Stainless Steel Trefoil type anchor Kg 10.
• Stainless Steel stem plate with mooring fairlead integrated.
• Galvanized 8 mm steel chain, 75 mt length with swivel.
• N. 6 flush deck cleats,N. 2 on the bow, N 2 mid ships, N. 2 at stern.
• N. 8 Pushlock along the toerail toward the CL. for fenders.

Dinette

• C shaped lounge with folding CL seat.
• Drawer below seats.
• Teak covered hi-low table.
• Hatch with direct access to bilge area.
• Hatch with access to gasoline tank inspections.

Galley

• Stainless steel sink with hot-cold mixer faucet.
• Refrigerator 110 l.
• Freezer sunk in countertop 50 l.
• Induction cooktop with two burners.

Steering station

• Double helm seat in front of the galley.
• Helm console with instruments and engine controls and various, 2 Garmin Display 12?.
• 3? magnetic compass.
• Mercury electronic engines controls.
• Ongaro stainless steel steering wheel.
• Hydraulic steering pump.

Upholstery and canvas

• Dinette cushion with Sunbrella washable external cover.
• External cushions with closed cell foam and with Sunbrella washable external cover.

Interior material

• Furniture and bulkheads and hull linings off white lacquered with teak trims, doors frames bulkhead and teak doors.
• Cabin sole made of marine grade plywood and finished with teak.
• Door handles, and interior fittings in polished stainless steel black mat.

Cabins

Twin size bed with ?V? layout.

• N. 2 locker with drawers.
• Drawers and storage under berth.
• 220V outlets.
• 1 opening deck hatch.

N. 1 sliding sofa / bed.

• - Cabinets and bookshelf.
• - Hatch and fixed porthole

Bathroom

• Sink with shower mixer & support. storage below and vanity mirror.
• Retractable shower.
• Hot-cold lever mixer.
• Electric toilet.
• 220 V AC outlet.
• Complete set of bathroom accessories.
• Opening deck hatch.

Upholstery

• Foam berth mattresses with lining.
• Bedspreads and cushions made of Sunbrella fabric.
• Clear leather like vinyl ceilings.

• N. 2 out board engines Mercury Verado 300 cv V8 4.6L.
• N. 2 integrated gearboxes.
• N. 2 Stainless steel propellers.

Fuel system - Petrol

• N. 2 drains in stainless steel of 50 mm on portside deck.
• Aluminium fuel tank of 242 UK gallons (1100 lt) capacity with fills and supplying engines.
• Tank level gauge at steering station.
• RINA approved flexible fuel pipings.
• Racor filters for each engine.

Fuel system ? Diesel

• 50 mm Stainless steel fuel fills on Starboard deck with drain.
• PVC fuel tank of 15 Uk gallons (57 lt) capacity, with inspection and cleaning port
• including fills, supplying generator.
• Tank level gauge at steering station.
• Racor filter
• RINA approved flexible fuel piping.

Cooling and exhaust system

• Engine cooling system with heat exchanger.
• Bronze seacocks with valve.
• Raw water strainers with removable stainless steel filters.

Ventilation

• Air intakes from deck house sides grids for the ventilation of the petrol tank and the
• and bildges.

Fresh water system

• Stainless steel flush fill on deck.
• N?2 structural GRP 132 UK gallons (200 lt.) each tank with inspection ports.
• Water level gauge at steering station.
• Fresh water pressure pump.
• 220V AC, 25 lt boiler.
• Water distribution system for galley, head and cockpit shower.
• Cockpit shower with hot and cold water.

Salt water system

• Raw water pressure pump.
• Manifold for distribution to WC
• Anchor locker chain washer.

Grey water system

• Grey water tank for head sink and shower including 12V drain pump.
• Galley sink with overboard discharge.

Black water system

• N. 1 electric toilets.
• Black water polypropylene tank, 42 lts. Capacity, with electric sump pump and Y
• valve.
• Alarm for full tank, valves manifold for dock / overboard discharge.

Bilge system

• N. 4 12V DC automatic bilge pumps. One in aft peak, one mid ship / storage bay,
• one for cabin / forepeak.
• Bilge pumps have automatic switch floats and manual override switches on helm
• console.
• N.1 emergency bilge pump in cockpit with three-way valve to drain all bilges and
• overboard discharge with siphon and safety valve.

220 V AC

• Watertight inlet for shore power 32 Amp.
• Generator 6.0 KW 220V 50HZ.

12 V DC

• Service batteries set 12V 510Ah.
• Engines and genset start batteries set 12V 200Ah.

Electrical panels

• Main distribution panel.
• Batteries switch panel.
• N. 2 Garmin display da 12?.
• Cockpit control panel.

Equipment

• 1 12V 80Ah battery charter.
• 2 12V 80A engine alternators.
• 1 Inverter 1000 W.

Lighting

• Watertight led spots in head, dinette and galley.
• Led spots in accommodation.
• Bed reading lights.
• N. 5 watertight cockpit foot lights.
• C.E. approved navigation lights

Various

• Register approved navigation lights. Switches for navigation lights on helm console.
• Earthing system.
• Cathodic protection with sacrificial anodes.

• N. 1 Garmin VHF.
• Integrated Hi-FI music system, 2 dinette speakers and 2 watertight speakers in cockpit.

• Firefighting system near the gas tank compartment as per RINA regulations.

Delivery and documents

• Sea trials.
• System test.
• CE / RINA certification (16 people).
• CE approved owner?s manual.
