GUEST ACCOMMODATION

?

SERENISSIMA I sleeps up to 10 guests in 5 cabins.

The master cabin is located on the bridge deck aft, featuring both a walk-in wardrobe and ensuite bathroom. The master cabin leads directly out onto a private deck with a small dining area, sun pads and jacuzzi.

The yacht?s main deck interior space is dedicated to guest entertainment, with a traditional aft main salon and dining room leading through to the midship guest lobby. Forward is a guest cinema room, with drop down balcony and walk-in wine cellar.

The lower deck features 4 further guest cabins. The forward cabins are twins, each with their own ensuite bathrooms. The aft cabins can either be set up as separate double cabins, alternatively, can be opened to make a full beam VIP suite.

An elevator and central staircase connect the interior decks.

Up to 9 crew are accommodated in 5 crew cabins, including a separate captain?s cabin. All crew cabins are located forward on the lower deck.

?

EXTERIOR DECK SPACES

?

The primary guest exterior entertainment space can be found on the sundeck, which has been split with large, glass panels midship to shelter the aft area. The sundeck forward offers a large jacuzzi and sun pads. Midship, under the hard top shelter, can be found a dining table for 10 guests with further seating found aft around a firepit.

The bridge deck offers a private space for the owner, with direct access out of the master cabin. In addition, there are walk around side-decks leading to the flush foredeck. The main deck aft accommodates the primary guest tender to port, with additional guest seating to port. The main deck aft leads down a central staircase to the generous swim platform. There is a secondary tender garage forward on the main deck, to accommodate the rescue tender and jet skis.

?

ENGINE ROOM

?

Main Engines: 2 x CAT C32 Ditta Acert 1,450 BHP

Port Engine Hours: 508

Starboard Engine Hours: 508

Gearboxes: 2 x ZF 3351 1:4478

Propellers: 2 x Teignbridge 5 blade

Exhausts: Water cooled + Urea

Generators: 2 x Caterpillar 188kW

Port Generator Hours: 414

Starboard Generator Hours: 434

Night Generators: 1 x Caterpillar 86kW

Night Generator Hours: 538

Alternator: Leroy Somer AC 400V / 50 Hz

ME Starter: 24v Electric

Steering: Data Hydraulic DDS 2 x 1100

Air Compressor: Gianneschi

Bilge Separator: EPE Poseidon

Bow Thruster: SP SAC 1400 Electric

Stern Thruster: SP SAC 1400 Electric

Stabilisers: Humphree Fins Zero Speed?

Bilge Pumps: 2 x Gianneschi

Fresh Water Pumps: 2 x Gianneschi

Hot Water Pumps: 2 x Wilo Top Z 30/7 R6

Fuel Transfer: Pump + 2 x Alfa Laval MIB503

Fuel Separators: 2 x Alfa Laval MIB503

Boilers: 3 x Gianneschi 150L

Water Softner: Idrofast 9100

Toilets: Evac Vacuum Optima Prestige

Water Treatment: Hamann HLCP025

HVAC & Chilled Water: Crusair / Dometic

AC Chillers Guest: 393,000 BTU

AC Chiller Technical: 129,000 BTU

ER Ventilation: 2 x Gianneschi + Fan Coil

AMS: Boning

?

TANKS

?

Fuel: 64,000L

Fresh Water: 14,000L

Grey & Black: 7556L

Bilge: 700L

Sludge Water: 700L

Lube Oil: 770L

Dirty Oil: 770L

Urea: 4,350L

?

FIREFIGHTING

?

Pumps: 2 x Gianneschi ACB631/B

Emergency Pump: Ganneschi MACB 531

Fire Extinguishers: Viking

ER Firefighting: Hafex Aerosol

Alarm & Monitoring: Siemens

Heat Detectors: Galley & ER

Gas Detector: Forward Garage

?

ELECTRICAL SYSTEMS

?

400/230 VAC and 24 VDC System

Main Generators: 400 VAC 50 Hz

Emergency Battery: 24 VDC

Shore Power: 208 ? 440 VAC 45 ? 65 Hz

Main Lighting: Cantalupi 230 VAC 50 Hz

Underwater Lighting: Cantalupi

Emergency Lighting: 24 VDC

Service Batteries: 24 VDC

Batteries: 24 VDC

Circuit Breakers: Schneider

Shore Power Converter: Magnus

Shore Power Cable: Hubbell 30m

Inverters: Victron

?

NAVIGATION / AV

?

Horn: Kahlenberg

Navigation Lighting: Lopolight 48 VDC

Central Alarm System: ECR Marine, Boning

Navigation System: Furuno GP 170

Entertainment: Sonos / Pioneer

Radar: Furuno FAR2219BB / PM X Band

ECDIS: NS4000

AIS: Furuno FA170

Wind indicator: 110WX

Auto Pilot: AP70

EPIRB: Sailor 4065

SART: Sailor 5052

Handheld VHF: Sailor SP3520

VHF: Sailor 7222 DSC Class A

Inmarsat C: Sailor 6110 220V AC / 24V DC

Radio Telephone: Sailor 6310

Navex: Sailor 6391

BNWAS: Walker P7007

Echo Sounder: Furuno FE 800

Speed Log: Furuno DS85

Compass: Cassens & Plath 33005

CCTV: Vivotek FD8366-V

WIFI: Ruckus ZoneFlex R320 / T300

4G: A-SPLT

?

AV SYSTEMS?

?

B&W Speakers + Subwoofer

Sonos

Lutron Lighting System Throughout

Guest Cabin TV?s: Samsung 43? 4K UHD

Salon TV: Samsung 75? QLED

Master Cabin TV: Samsung 55? QLED

Cinema: Samsung 85? QLED

Music AMP: Bose PM8500N / Marantz Cinema 60

TV: GrandStream IP TV

Telephones: Gigaset C530

?

GALLEY & LAUNDRY?

?

Cold room on tank deck

Cooled garbage locker

Cook Plate: Miele KM 7897 FL

Oven: Miele H2861BP

Dishwasher: Miele PFD 400 SEE + Hobart GCP 10B

Fridge/Freezer: 6 x 220V Liebherr WB

Ice Makers: Hoshizaki

Coffee Machine: Miele CM 6350

Wine Cellar

Extractor: Custom Mengi Yay

Steam Oven: Rational SelfCooking Centre

Washing Machine: 3 x Miele PWM507 DP

Dryer: 3 x Miele PT 7135 3FAZ

Drink Fridges: Liebherr

?

ANCHOR & MOORING

?

Windlasses: 2 x Data Hydraulic DZC 3300

Anchors: 2 x 316L Stainless Steel

Anchor Chains: 2 x 250m Galvanised

Bollards: 10 x 316L

Capstans: 2 x Data Hydraulic DZC 3000

?

DECK EQUIPMENT

?

Balconies: REM Marine

Transformer: REM Marine

Wipers: 5 x 24VDC

Caulking: Sikaflex

Gangway: REM Marine

Side Boarding: REM Marine

Swimming ladder: Manual

Tender Cranes: REM Marine

?

PAINT

?

Primer: Awlgrip International?

Filler: Awlgrip International?

Top Coats: Awlgrip International?

Antifouling: Awlgrip International?

?

SAFETY EQUIPMENT

?

Life rafts: 4 x Viking 12 person

Search Lights: 2 x Sanshin 150W

First Aid Kit: SOLAS

Fire hoses: 5

?

TENDER

?

Riva Ariston No. 131

Specifications and details of this vessel are provided in good faith for informational purposes only. Data regarding the specifications, operating characteristics and condition of the vessel was obtained from sources believed reliable but is not guaranteed by owner or brokers. Buyer assumes responsibility to verify all speeds, capacities, consumptions and other measurements contained herein and otherwise provided and agrees to instruct his agent or surveyor to confirm such details prior to purchase. Vessel is offered subject to prior sale, price and inventory changes and withdrawal from market without notice.

?

Engine hours are as of the date of the original listing and are a representation of what the listing broker has been told by the owner and/or actual reading of the engine hour meters. The broker cannot and does not guarantee the true hours. It is the responsibility of the purchaser to verify engine hours, warranties implied or otherwise, and major overhauls as well as all other representations noted on the listing brochure.
