MAIN CHARACTERISTICS

BUILDER                                               HARGRAVE SUPERYACHTS

ACCOMODATION                                10 GUESTS + 7 CREW

CLASSIFICATION                                 Rina Pleasure Yachts

CÌHULL oMach Y UNRESTRICTED NAVIGATION

LENGTH OVER ALL                            35.365 meters             / 118 ft

LENGTH WATER LINE                       31.400 meters  / 103 ft

BEAM MAX                                          7.92 meters   / 26 ft

DRAFT             (max)                           1.850 meters / 6 ft

DISPLACEMENT (Light Ship)           125 Tonnes

DISPLACEMENT (Fully loaded)      160 Tonnes

GROSS TONNAGE                            320 GT (Approx.)

TOP SPEED                                        19.05 Knots

RANGE at CRUISING SPEED            945 Nautical Miles

PROPULSION

MAIN ENGINES                        2 x CAT C32 1900HP @ 2300 Rpm

GEARBOX                                  ZF53050 SERIES 2,98:1

GENERATORS                            2 CAT 75 kW

ELECTRIC SYSTEM    20 / 208 VAC 3P 60Hz  Main Service

                            24VDC Service and Engine Start System

TANK CAPACITY

Diesel Oil                    23.100 Lt      / 7,880 Gallons

Fresh Water                 5.000 Lt         / 1.200 Gallons

Black Water                 2.650 Lt         / 500 Gallons

GreyWater                    3.300 Lt         / 826 Gallons

BUILD / CONSTRUCTION

HULL / SUPERSTRUCTURE: CARBON REINFORCED E-GLASS - EPOXY COMPOSITE SANDWICH

OPEN DECK: HAND LAID BURMESE / MYANMAR TEAK OR NON SKID PAINT

PAINT SYSTEM: INTERNATIONAL and AWLGRIP

MASTER EQUIPMENT LIST

Airhorn                                                   Kahlenberg

Anchor winch                                         Maxwell

Appendages & equipment                      Rotork / Kurtek / Halyard / Rubber Design

Alarm & Monitoring system                    Beijer - Wago

Anchor                                                   316L Stainless Steel

Audio / Video                                         Savant / Apple

Battery chargers                                  MasterVolt

Batteries                                              MasterVolt

Bow/stern thrusters                             NAIAD

Exhaust system                                    Halyard

Fuel oil filters                                          Racor

Galley/pantry equipment                        (SEE INTERIOR DESIGNER SPECS)

HVAC                                           CRUISE AIR

Hydraulic components                    NAIAD

Insulation                                            FyreWrap

Sun Deck Jet Tub                                 Spa Manufacturers

Navigation & communication equipment  FURUNO

Pumps                                                    HeadHunter

Rudder actuator                                      JASTRAM

Sewage treatment                                 Headhunter

Stabilizers                                             Naiad

Safety Equipment                                 RFD / Viking

Toilet system                                          Headhunter

Fridge&Freezers                                Sub-Zero

Underwaterlight                                    Ocean LED

Lighting                                                  BCM / Palagi

Lighting Automation Control              LUTRON

DECK EQUIPMENT

GANGWAY                                      BESENZONI or Equal

SWIM LADDER                                316L Stainless Steel

JETSKI CRANE                                BESENZONI or Equal

JETSKI STORAGE at                         SUNDECK

HANDRAILS                                      316L STAINLESS STEEL

WINDLASS                                      2x Maxwell Vertical Windlass

CAPSTANS                                        2x Maxwell Capstans

MOORING BOLLARD                       CUSTOM 316L S.STEEL.

ANCHOR                                            2x 180 Kg Pool Type HHP Anchor

WX PANTOGRAPH DOORS FREEMAN

SLIDING DOORS                                BOFOR

WATERTIGHT DOORS - BOFOR

DECK HATCHES BOFOR

AFT BEACH SHELL DOOR             HYDRAULIC OPERATED

SAFETY EQUIPMENT

LIFE RAFTS                                VIKING 2 x 16 PERSONS

FIRE PROTECTION                           FM200

FIRE & ALARM SYSTEM   SEAFIRE (Monitoring at Wheelhouse)

CCTV SYSTEM                               SAMSUNG

Owners' Walk Through by Deck

Main deck walkthrough

Full beam owners' suite forward with California king-sized berth, his & her bath, his and her walk-in closets, and seating area.

Following is a commercial-sized galley with a large center island for MEAL service and a dinette area with access to crew quarters.

Next is the formal dining area with seating for 10 and storage.

Next is the main salon with l shaped settee and five chairs, tables, walk up bar, and an entertainment center with a flat screen TV.

Through the hydraulic sliding doors to the aft deck, which featured outdoor dining and high low table, a wet bar, stairs up to the bridge deck, and double staircases down to the beach club with an extended swim platform.

Lower cabin deck:

Four guest suites, each with king-sized berths and a private spiral staircase to the main deck.

All the way forward in the bow is a best-in-class crew area with three private cabins with upper and lower berths, each with a private head, a comfortable lounge area, mini galley, washer and dryer, and lots of extra storage. The captain's cabin is located on the bridge deck.

The bridge deck:

The main navigation area is forward and offers full privacy with extensive electronics, large screens and monitors, an adjustable helm chair, bench seating for guests, and access to the captain's cabin on the starboard side.

The upper salon features a large L-shaped settee and chairs to port and a dramatic bar for three guests looking out to see on the starboard side, along with a large wine locker and extra storage.

Exiting through double sliding glass doors to a large outdoor entertaining area that includes a large round dining table for ten, and then all the way aft to a full-width lounge seating area with cocktail tables.

The upper sky deck

A fun area for owners and guests only featuring a large heated Jacuzzi forward with great views, a large settee and table with three additional chairs to port, a large stand-up bar with four stools to starboard, a full-sized enclosed head, an outdoor grill, sun lounger chairs, and two jet skis, all under a stylish fiberglass hardtop.
