General

- Vinylester resin with marine-grade structural foam. High density allows for high-temperature resistivity and a particular advantage in thermal and acoustic insulation.

- Reinforced collision bulkhead

- Fiberglass with infusion lamination manufacturing technology

- Painted exterior surface with professional-grade Alexseal polyurethane paint and epoxy-based primers. Highest gloss and color retention compared with gel coat or other paint brands. Guarantee color match by Alexseal. No fading, yellowing, and minimum maintenance with no annual compounded necessary on exterior paint. For the first 3 years just use soap and water (Unique OA standard feature, not an optional up-charge like competitors).

- 2" elliptical 316L Stainless steel handrails & stanchions, main deck. 1-1/2" on FB. Elliptical conforms better to human grip than traditional round rails. Provides greater "grip strength" for safety and comfort (Unique OA feature)

- All exterior hardware to be S/S 316 or to manufacturer requirements

- Ocean Alexander employs various techniques to reduce sound and vibration. Focusing on providing a quiet and comfortable yachting environment through various proprietary techniques of controlling sound and noise transmission. Some of these techniques include multiple insulation barriers including reflective materials, absorptive materials, dampening materials, air pockets, and flexible isolation mounts. Ultimately resulting in vibration/sound levels that are industry-leading and at times 1/2 to 1/10 of ISO-6954 sound levels (Unique OA feature)

- Weather-tight bulkheads with further sound and temperature insulation

- Marine grade aluminum beam. Provides greater rigidity, and reduces movements and "abrasive" sounds while underway. Also allows for one of the largest uninterrupted glass/window spans in the industry. (Unique OA feature)

Hull / Bottom

- Rub with S/S insert

- Three coats of Pettit primer, hi-build epoxy barrier coat, and covered with three coats of Pettit self-polishing bottom paint (Unique OA feature, optional on competitors)

- Bronze through-hull fittings

Deck / Pilothouse

- Upgraded Ultra Anchor with 400' of chain (original anchor and chain supplied as a spare)

- Chain locker in the bow with hinged access

- Removable swimming ladder

- White non-skid fiberglass decks

- Port and starboard boarding gates

- Ventilation hatch fwd. trunk top

- Fiberglass staircase from the deck to Flybridge with teak soles

- Fiberglass swim platform with teak decking

- Composite hardtop with aluminum beam support (OA standard feature, often a $100,000 competitive option)

Electrical

Air Conditioning

- Dometic® systems throughout, rated for "Extreme Tropical Climates" (with reverse cycle for operation down to 40°F water temp)

- Refrigerant type is accepted worldwide under the Montreal Protocols

- Where possible A/C exits from custom-made ceiling panels hidden from view. Shortens A/C ducting thus improving efficiency and speed of cooling by over 20%. Also reduces dB reading by over 7 dB (Design cues from OA120)

Main Engines

- Twin Volvo IPS1200. Three control stations: FB & PH & Cockpit

- Volvo IPS Dynamic Positioning w/ Joystick - UPGRADE

- Includes 3rd station joystick in cockpit

- Clear wake exhaust

- Built-in line cutter

- "Prop Speed" on props

- Joystick driving

Bow Thruster

- Electric Bow Thruster with variable speed - UPGRADE

Windlass / Mooring

- Electric windlass, RC12

- Vertical electrical rope winches at aft deck

- Chain counter

Generator

- (2x)Kohler 23KW generator - UPGRADE

- 24V Fisher Panda automatic DC battery charger

- Generator set resiliently mounted and installed with sound shield & vibration dampener (Unique OA feature)

- Generator exhausts with fuel/ water and gas/ water separator

- Generator exhausts to be water-drop type per "Centek", Marine Exhaust Co." or equal. Reduces noise & vibration

Fuel System

- Aluminum fuel tank with sight gauges and tested to International Standards 33CFR 510(a) w/ high and low fuel level alarm system

- Filler for fuel tanks on both sides. (Unlike others where fueling is only possible on 1 side. This unique OA feature allows for concurrent and faster fueling & negates the need to move the boat to complete fueling)

- Maximo Wireless Yacht Controller with Joystick Function ($17,000 Upgrade)

- Volvo Penta Interceptor Electronic Vessel Control w/automatic TRIM ASSIST for fully automatic ride control

- Sleipner Hydraulic "Zero Speed" Stabilizer - UPGRADE

- Boston Whaler SuperSport Tender with 40hp Mercury Outboard

- Stainless steel rails on the sides of engines

- Fire extinguisher system with engine-shutdown feature

- Manually controlled adjustable Delta-T® fans for engine exhaust located on superstructure instead of hull side.

- Intake/ exhaust fans with de-mister to eliminate moisture from the intake airflow to keep dry in machinery spaces.

- Pantograph windshield wipers & washers w/ intermittent function

- Kahlenberg™ heavy duty air horn

- Two Stidd™ mechanical helm seats on F/B

- One Stidd™ mechanical helm seat in Pilothouse

- Pantograph door on port and electric salon door

- Teak decked custom fiberglass swim platform with remote operated 1500 lbs. capacity 316L Stainless Steel hydraulic lift

Fresh Water System

- Stainless Steel water tank

- Fresh water wash down, at bow & stern

- Dockside water connection

- One 28-gallon high-efficiency water heater with high-density fiberglass insulation

- Sea Recovery 1200GPD water maker - UPGRADE

- Fast recovery 40-gallon hot water tank - UPGRADE

- Electric on-demand continuous water system - UPGRADE

Bilge / Discharge

- 24V shower sump pumps

- Lighted engine compartment

- Automatic bilge pump - with manual and automatic switches including high water alarms

- Lighted bilge (Unique OA Feature)

- Common drainage system for bar sink, shower, bilge & exterior deck

- Fresh Air & Bilge Package - UPGRADE

- OA fresh air system with HEPA-filtered fresh air drawn from outside and vented to lower staterooms for constant fresh, clean air. Makes for a clean and healthy environment that reduces free radicals and increases oxygen levels ( from the OA 100' feature).

- OA proprietary "dry bilge ventilation system" with dedicated bilge exhaust to the outside. This provides instant airflow to keep the bilges dry and mildew-free. Any moisture from consideration is evacuated outside the yacht to keep a clean and healthy cruising environment

Navigation Package (OA Standard Feature)

- Garmin 8600 Series Black Box with 24" screens (Two screens - lower station, Two screens - upper station)

- Garmin GRID remote input device at Stidd® Helm (FB and PH)

- Garmin 12KW Open Array Radar

- Garmin Autopilot GHP Reactor

- Card Reader

- Garmin VHF at Helm (FB and PH)

- Garmin AIS with NMEA GPS

- Garmin Sonar Module with Transducer

- Garmin Marine Camera (2x engine room, 1x aft deck)

- KVH TracVision HD7 with DIRECTV® receivers

- Ritchie Compass 5"

AC / DC System

- AC outlets 120V

- AC distribution panels with remotely operated hydraulic-magnetic circuit breakers

- DC distribution panels with electronically programmable

- Circuit breakers

- Upgraded AGM Battery Bank with -15C to 40C operating temp and low 3% per month self-discharge rates

- 24V Fisher Panda with AutoStart for Battery Charging

- 2x 50A Shore power receptacle at transom w/90' Cable Master with Iso-Boost 100A transformer (OA is unique in making this a standard vs. optional to clean & boost questionable shore power to better protect sensitive equipment onboard.)

- Battery paralleling system switch between service and engine

- Service battery switches

Battery Chargers

- Inverter PACKAGE - UPGRADE

- Dual 60 AMP charger to inverter/charger ( 3000W/70 AMP) - UPGRADE

- Blue Power full-function programmable controller

- 30 AMP for engine

- 30 AMP for bow thruster w/option BONDING SYSTEM:

Bonding system

- The vessel's bonding and grounding systems shall include copper straps secured to the hull and running the full length of the vessel parallel to the centerline. Engines, generators, metallic through hulls, strainers, and pump bodies connected to the bonding strap

- Engine battery isolation switches with paralleling

- Generator battery isolation switches with paralleling

- GFI (120V) AC outlets in potential "wet" areas. In addition, the entire boat is dual-protected via ELCI Octoplex breakers. (OA is unique in the industry to provide dual protection GFCI & ELCI)

- Octoplex NMEA 2000 Network electrical control system. Based on aerospace technology for remote activation, control, and status reporting of AC and DC breakers. Monitors power sources (AC and DC) for voltage, frequency, and amperage abnormalities and provides visual and audio alerts. Includes enhanced circuit breaker functionality with no-load indication and usage information with touch screen monitor that is user reconfigurable. Brown-out configurable control through auto load shedding is included where designated equipment (e.g. navigation and other essential systems) remains powered-on while automatically switching other systems off. Octoplex NMEA 2000 Vessel system monitors main access doors, tank level, bilge level and battery current, voltage and temp. (Unique OA standard feature, not an optional up-charge like competitors)

Lighting

- 24V LED lights (Specially tuned color temperature for Ocean Alexander)

Other

- Labeled Vimar™ switches and outlets

Salon

- Evan K Marshall custom designs salon furniture and sofa. The sofa includes concealed drawers for intelligent use of space and increased storage

- Removable ceiling panels

- Wood paneling and cabinetry

- Enlarged windows in salon with custom engineered solution allowing for industry leading window expanse. Incorporate (where possible) aircon outlet from ceiling, provides unobstructed view to outside.

- 50" LED TV with DVD, Satellite receiver, amplifier system w/sub-woofer and Sonos music streaming system - UPGRADE

- Onboard Internet, driven by commercial grade 4g SIM card capable WiFi router (5g Capable)

- Wood flooring in lieu of carpet - UPGRADE

Master Stateroom

- King-sized berth with upholstered headboard

- Two nightstands

- Chaise lounge on port side with vanity

- Private head with stall shower

- Safe in master stateroom

- Cedar-lined, full-height hanging locker w/ auto lighting

- Enlarged windows with custom engineered solution incorporating composite beams and "sandwiched glass" construction technique from classed vessels. Allows of 38% greater visibility and incoming light

- 32" LED TV with DVD, Satellite receiver, amplifier system w/sub-woofer and Sonos music streaming system - UPGRADE

- Custom granite stainless insert floor in front of Master Stateroom - UPGRADE

Heads

- HansGrohe™ faucets for sink and shower

- Fiberglass stall shower w/ one-piece glass door. Industry leading seamless one-piece shower stall design provides long term protection against moisture, water intrusion behind the shower panels that can cause foul odors and water damage.

- Planus™ toilet system throughout

- Cambria floor in heads in lieu of Amtico - UPGRADE

Galley

- Wood panel and cabinetry with positive-latch doors Prov

Wood panel and cabinetry with positive-latch doors Provides containment of stored objects while underway

- Storage cabinets with fully dovetailed solid wood drawer construction

- Franke® Sink with Franke® Pull out faucet

- Fisher Paykel® Refrigerator/Freezer

- 30" Jenn-Air® Microwave

- 30" Jenn-Air® electric induction cook top

- Whirlpool® garbage disposal

- 30" Jenn-Air® electric convection oven

- Bosch® dishwasher

- 15" Jenn-Air® Trash compactor

- 24" Jenn-Air® wine cooler - UPGRADE

- Seagull water purifier ( ADEX design award winner w/filtration to 0.1 microns & EPA certification) for Galley sink and ice-makers - UPGRADE

Interior Decor

- Interior Color Scheme: Titanium

- Stone Package: Dark

- Evan Marshall designed the interior pilot station and display pods with matching wood and designer fabrics. Ergonomically designed and laid out to enhance pilot experience/performance

Evan Marshall designed the interior pilot station and display pods with matching wood and designer fabrics. Ergonomically designed and laid out to enhance pilot experience/performance

- Stained wood paneling and cabinetry

- European door handle

- Stainless steel hardware

- Satin varnish for interiors

- Positive latch drawers & cupboards

- Fabric-covered walls

- Oversized hanging lockers

- European washer/ dryer

- Air extraction in each head

- Ocean Alexander wood floor is custom-made in Kentucky with a solid wood top surface with the same wear capacity as solid ¾'' wood flooring. It uses 7 layers of European birch assembled in a cross-grain direction with a top layer of exotic hardwood to match the interior of the boat. (Unique Ocean Alexander Feature)

- UPGRADE: Sliding Starboard guest berths, convert from two singles to single queen with additional hidden nightstand - UPGRADE

- Crew quarters with dedicated bunk and walk-in wet head and electric toilet - UPGRADE

- 6-zone Sonos system allowing streaming music and stereo sound for zones with TV. Includes this areas: Salon, Master, Flybridge, Galley, Aft Cockpit, and Bow seating area - UPGRADE

- Onboard Intranet, driven by commercial-grade 4G SIM-card capable Wi-Fi router - UPGRADE

- VIP 28" LED TV with Satellite receiver - UPGRADE

- Starboard stateroom 28" LED TV with Satellite receiver - UPGRADE

- Port stateroom: 19" LED TV with Satellite receiver - UPGRADE

Exterior

- Hardtop with dedicated custom S/S ladder

- Full Canvas Enclosure for Cockpit & Flybridge

- Venturi

- Flip open hatch, bridge to pilothouse

- Electric Stainless sliding salon door with safety light curtain that senses an obstruction. Also includes a "foot-kick button" control for operation when both hands are full with food trays/other items.

- Largest Flybridge area in its class with Ocean Alexander's "cab-fwd" design, the Flybridge steering station is moved fwd to allow for better visibility and lengthens the total Flybridge area available for entertaining.

- Nonskid deck throughout

- Teak tables at Aft deck & FB seating areas

- Boarding gates on Port & Stbd sides

- Backlit OA logo

- Flip Open Hatch for Aft deck to FB

- Teak decking on swim step and swim step deck steps

- Flybridge Wet bar with sink and refrigerator/ice-maker

- Teak decking package - UPGRADE

- Main deck (aft deck to midship first step)

- Steps from the aft deck to Flybridge

- Aft deck custom fiberglass cabinetry with sink and refrigerator/ ice-maker - UPGRADE

- High output underwater lights (Three at stern, two on each side at Master) - UPGRADE

- Aft deck - custom flip down from ceiling 32" LED TV - UPGRADE

- Flybridge deck - custom flip down from ceiling 32" LED TV - UPGRADE

- Custom Port storage cabinet on Flybridge deck with refrigerator and dedicated ice-maker - UPGRADE

- ACR searchlight 300K and recessed rear flood lights on radar arch and aft cockpit - UPGRADE

- Custom exterior protection canvas and windshield mesh cover and mesh screens added to all opening port lights throughout the vessel - UPGRADE

- Two bar stools and 24" Electri-Chef BBQ on Flybridge deck - UPGRADE

- S/S transom gates from aft deck to swim step - UPGRADE

- Fenders, lines, flare kit, fire extinguishers, bell, safety first aid kit

The Company offers the details of this vessel in good faith but cannot guarantee or warrant the accuracy of this information nor warrant the condition of the vessel. A buyer should instruct his agents, or his surveyors, to investigate such details as the buyer desires validated. This vessel is offered subject to prior sale, price change, or withdrawal without notice.
