Description
DECK    High-tech composite construction under vacuum using oven post-cured epoxy impregnated, stitched biaxial E- glass and water resistant 1" AIREX C70 foam core.
Solid glass or high compression Penske Board core in way of all thru bolted hardware and over-sized epoxy G-10 pressure- laminated composite backing plates for all cleats and stanchions.    Hull to deck fused together as monocoque structure with cyano-acrylate adhesive with shear strength of 1.5 tons per square inch and with mechanical fasteners of the gunwale guard on 8-10" centers.    Exceptionally strong, fully-molded (inside & out) and gelcoated windshield frame/posts with hardtop.
Convertible pilothouse enclosed by clear, weather tight, zippered roll-up in place, StrataGlass windows Window in aft entry door has combo window/screen    Dual fully-opening windshields with safety glass and electric wiper/washers. Electro powered.
Stidd 500N Low-Back Admiral Recliner Piloting Seats on adjustable pedestal that lowers to allow chairs to swivel 360 degrees for living room setting.    Removable teak single-leaf dining table    Stainless 1-1/4" bow rail with ITT Jabsco 400,000 cp halogen spotlight and 16" teak burgee staff.
Muir windlass, polished stainless bow guard, bow roller, self-launching Lewmar claw anchor w/250' rode/Chain and high-pressure fresh-water, chain/rode washer operable from helm.    Deck drains divert dirt/soot/dew/rain into gray water system and out transom...rather than onto topsides.
12" custom 316L stainless custom bow cleats (2) and 10" side-deck and stern cleats (4) with matching bow chocks (2) having 22mm opening    316L Stainless 1" handrails (6 pairs) on cabin trunk, pilothouse roof, side windshield frame, aft of pilothouse for boarding and under pilothouse roof aft of piloting chairs and companionway entrance.    Molded side-deck access steps (P&S) in cockpit.
Large storage compartment under cockpit sole with hinged lids,    Systems compartment w/hatch under pilothouse sole.
20"W x72"L x40"H pilothouse settee lockers P&S w/piston-activated lockable lids. Lockers have vinyl flooring and mesh storage bags for fenders, docklines, power cords, hoses, mountain bike, hard luggage and/or golf club storage.
Teak storage drawers (2) under piloting seats.
Pilothouse settees with UltraLeather cushions and backrests in color of choice. Settees convert to 6.5' berths with natural latex memory foam cushions.
Lewmar 20"x20" (2) hatches in saloon, 10"x10" (2) in galley and head and Lewmar 15"x20" (2) vent hatches in pilothouse with Ocean screen/shades.
4 opening cabin trunk portlights with screens/shades . • Gloss-varnished teak bi-fold companionway door and 4- section hinged cover with brass combo lock.
Aft cockpit seat doubles as engine cover, hinging upward 45 degrees on power screw lifts for engine access with bolstered UltraLeather bottom and backrest cushions and Stamoid weather cover.
Two aft facing cockpit seats with storage lockers and bottom cushions.   Teak flagstaff
Custom Armstrong swim ladder    ELECRONICS AND EQUIPMENT   Horn AFI Stainless Dual Trumpet Electric Horn   Chartplotter Raymarine E125 Hybrid Touch w / integral WiFi for iPad and Navionics Platinum Plus XL chip   Chartplotter Raymarine E165 Touch Screen Display   Fishfinder 350W Airmar Gemeco depth sensor with i70R multi- function display   Radar Raymarine 24 "4 KW HD color radar   VHF Raymarine 218   Autopilot Raymarine   Sky Hook Seastation Positioning System   Fishfinder Raymarine CP 570 Professional CHIRP Sonar Module   Spinning rod holders 4 pcs on rails and 3 pcs on transom   Electric anchor winch LEWMAR   Yanmar 6BY260HP 6 cyl diesels with ZT370 Sterndrives in lieu of Standard. Note: These engines have hydraulic multi-disc clutch that eliminates the "clunk" when docking with joystick, have greater thrust in moving   Standard 12V 150A generators   Digital engine display for tachometer / hours, oil pressure, water temperature, fuel level, fuel consumption and more. The Yanmar CANplus® 600 (CP600 ™) control panel i4.25 "diagonal LCD   Racor 500 series fuel filters with replacement cartridges.   Two Interconnected (with shut-offs), bright-finish, coated aluminum 370 lit each fuel tanks with Wema SUF American standard fuel level sensors   Parker 221FR USCG Class 1 flame retardant fuel hoses with steel wire braid   Automatic fire extinguishing system Seafire in the engine compartment with a portable fire extinguisher in the cab.   24 '' Edson steering wheel   Volvo Penta electronic steering with joystick.   Lenco cantilever electric transom plates.   Watermaker Shenker ZEN 50 12 V   Pressure hot/cold water for galley with Jabsco SensorMax 17 microprocessor controlled pump with variable-speed water pressure   Boiler 39 liters   Fresh water tank 370 liters   Three Rule 1100 automatic electric bilge pumps in bow and amidships compartments isolated by the main bulkhead under the wheel   Dometic Vacuflush toilet with 68 liter storage tank and fresh water flush   Stand-by manual bilge pump of increased productivity Bosworth with the drive from the cabin   Centralized gray water drainage through the transom to minimize hull penetrations   Waste water pan with strainer and transparent viewing window for shower, refrigerator and air conditioner condensate   Stainless Marelon seacock valves with strainers and double clamp hose connections   Marina fresh water inlet   Alarm system with notification to the phone and PC about the boat's GPS coordinates, the voltage in the boat network and the water level in the hold   Illuminated electrical panel, 12 V DC circuit breakers   Led lights   Engine compartment lighting   12 V sockets   Service batteries with a capacity of 400 Ah   Starting batteries of engines with 2 batteries 100 Ah each   Starting battery of diesel generator 100 Ah   All batteries, if necessary, work in parallel 700 Ah   Navigation and anchor lights   Anodes and galvanic isolator   Shore power system 230 V   Victron MultiPlus 12/3000 Inverter / Charger   Diesel generator Northern Lights 5KW M673D, 1800 rpm   MarineAir 16000 BTU Reverse Heat Cycle Air Conditioner   Heater Wallas 40D 12-volt thermostatically controlled diesel heater with air ducts in the wheelhouse, cabin and saloon   Fusion Stereo, Amplifier, MP3 / iPod Connector, 6 Bose Speakers
