Builder: Horizon Yachts
Built/Refit: 2010/2024
Type: Semi-Displacement Motor Yacht
Naval Architect: Horizon Yachts
Exterior Design: JC Espinoza - Greg Marshall
Interior Design: Claudia Drettman
Interior Decorator: JC Espinoza
Classification: Det Norske Veritas (fresh 2025 certificate)
Length: 41.15 m/135 ft
Beam: 7.98 m/26.2 ft
Draft: 2.3 m/7.7 ft
Hull Material: Composite/GRP/Scrimp Tech
Displacement: 336 at full load
GT: 398
NT: 120
Engines: 2x MTU 8V 4000 M70 1,550 hp
Max Speed: 15 knots
Cruising Speed: 10.5 knots
Economical Speed: 8.3 knots
Range at Max Speed: 570 nm - 2,000 RPM
Range at Cruising Speed: 2,700 nm - 1,200 RPM
Range at Economical Speed: 4,000 nm - 1,000 RPM
Generators: 2x Caterpillar C-44 90 kW
Fuel Capacity: 43,906 liters/11,600 gallons
Fresh Water: 7,570 liters/2,000 gallons
Lube Oil: 511 liters/135 gallons
Dirty Lube Oil: 795 liters/210 gallons
Wastewater: 5,000 liters/1,321 gallons
Ballast Water: 3,407 liters/900 gallons
Staterooms: 6, sleeps 13
Heads: 7
Crew Cabins: 4, sleeps up to 9
Crew Heads: 4

Engineering

• Sewage treatment plant rebuilt and all black and grey pumps serviced
• All tanks cleaned and coated where necessary
• Fresh water pump replaced with new Headhunter VFD pump
• All ducts and air handlers cleaned and mold remediation completed throughout
• Battery's replaced completely throughout including MAN engines, generators, house batteries, GMDSS batteries and emergency batteries
• New ER fan VFD's installed
• Annual service on water makers
• Main engine 5000 hr service
• Main engine cooling system rebuild
• Main engine fuel system partial rebuild
• Generator valve lashings completed on both
• Steering pumps complete rebuild
• Crew mess camera display installed
• Windlass annual service and inspection

Interior

• Main salon table refinished and wrapped
• All laundry and galley appliances annual service by Miele
• Black out blinds installed in master and VIP

Deck

• Main deck dining table refinished and wrapped
• All dive gear serviced and certified
• Annual haul, bottom paint, prop speed and all anodes replaced
• Annual flag and class surveys completed
• Annual LSA and FFE services completed

This exquisite full beam (28 ft) stateroom features a king bed, large flat screen TV, and massive ensuite with multi-jet shower and jacuzzi tub. There is also access from this suite aft to the skylounge.

A large comfortable lounge area with a seating area to relax and watch a large flatscreen wall-mounted TV. A beautiful custom-made cocktail bar with seating for 3 to starboard. There is also a small fridge, wine fridge and ice maker in the lounge along with stocked glassware cabinet on both port and starboard side.

Located on the forward main deck this spacious stateroom spans the entire beam of the boat (28 ft) and features a king bed, flat screen TV, walk-in wardrobe and a large ensuite complete with a bidet. Relax in complete privacy on the plush settee or prepare yourself for an evening of luxury at your personal vanity/bureau.

This bright king cabin features 5 portholes with marvelous sea views, a flat screen TV, large marble ensuite with bidet and rain shower. There is ample storage in his and hers wardrobes, plus a private mirrored vanity.

Warm, rich woodwork define these 2 identical luxurious forward staterooms. Each is able to accommodate couples or can be easily arranged as 2 single berths. Complete with all amenities these VIP cabins provide a wonderful refuge after a day in the sun.

This cabin, adjacent to the other VIP, features a twin bed with a pullman, capable of sleeping 3. It too has 5 portholes with marvelous sea views, a flat screen TV, large marble ensuite with bidet and rain shower, and a separate designated sauna room. There is also ample storage in his and hers wardrobes, plus private mirrored vanity.

• Peloton Cycle
• Peloton Treadmill
• Ice Bath
• Massage Table

• (3) Twin cabins aft on lower deck + 1 Captain cabin on main deck
• Lounge, comfortably seats 7
• TV and entertainment system
• Siemens range
• Siemens convection/microwave combination oven
• Siemens French door refrigeration
• Fridge freezer
• Icemaker in fridge
• Siemens dishwasher
• Keurig coffee maker
• Garbage freezer in adjacent aft companionway
• Miele washing machine
• Miele dryer

• Gearboxes- ZF Transmission ZF4540 Ratio 3.04:1
• Propellers: (2) 5-blade propeller
• Sterring System: Hydrive E-Series AC/DC
• Emergency Steering: Hydrive Manual steering (propeller, waterjets, cp propeller)
• Helm/Control Stations: 5- bridge, flybridge, (2) wings, aft
• Stabilizers: ABT TRAC - 440 with STAR Zero Speed
• Bow Thruster: ABT TRAC - 20" bow 16" stern B-7.5, S-6.5h
• Electricity: 170-510 V Single & 3-phase 50/60
• Shore Power ASEA: (2) AC30 60 kW 3.3.1
• Batteries: (8) Rolls AGM 12 Volt/260 AH
• Main Engine Start: Mastervolt AGM 12v/225 AH
• (2) Automatic Mastervolt chargers
• Generator Start: Mastervolt AGM 12v/160 AH
• (2) Automatic Mastervolt IVO Smart 24/15-3 Chargers
• Air Conditioning: Marine Air 450,000 BTU, 37.5 tons
• Interior Fresh Air: FAMU- Marine Air (3) units, (16) Air Handlers
• Air Compressor: JUN - AIR 2000
• Watermakers: (2) Sea Recovery- (1) 700 USG p/day, (1) 2800 USG per/day;(2) Grundfos, Headhunter Mach 5 & Excaliber
• Sewage System: Hamman Treatment Plant
• Fuel Filtration: ALFA Laval MIN-303
• Bilge Water Filtration: Gianneschi CP20 with commercial filter

• Cassens & Plath magnetic compass
• Anschutz gyro compass
• Furuno SC501 satellite compass
• Anschutz NautoPilot NP60 automatic pilot
• Furuno FE-700 echo sounder
• Furuno CH-250 searchlight sonar
• (1) Furuno MU201CR band range 120 nm radar
• (1) Furuno PM31 X band range 120 nm radar
• AIS Furuno Universal AID FA150 radar
• Furuno GP-150 GPS
• (2) Furuno with Max Sea Time Zero chart plotters
• (2) Hatteland touch screen display screens
• Furuno NX700 Navtex
• Furuno PP-510 weather fax
• Furuno DS-80 log
• Weather Data Walker 2020
• FLIR MU series cryogenically cooled camera- 5-mile range (DOD export approved)
• (2) ACR Artex searchlights

• (2) Starlink high speed internet up to 600 mb download when bonded
• (2) Furuno FM8800S fixed VHF
• (2) ICOM IC-M25 handheld
• SSB) Furuno FS-2570
• Panasonic TDA30 (2 lines, 13 extensions)
• Phontrch CIS3101 intercom
• Furuno foghorn/hailer
• Apple ship's computer
• HP Office jet printer

• (2) Maxwell VZ 4000 aft warping capstans
• (2) Maxwell VWC 6000 series- remote control and deck foot pedals
• (2) Kedge 250 kg stainless anchors
• (2) 125 m 16 mm anchor chains
• Hydromare 1,250 kg main tender davits
• (2) Opacmare 800 kg/500 kg
• Hydromare hydraulic side boarding ladder
• Hydromare passarelle aft boarding ladder
• Hydromare aft crew door
• Hydromare aft tender garage door
• (10) Ocean LED underwater lights
• (1) 80 lb Hoshizaki ice machine on main deck aft

• Starlink high speed internet
• Flat screen TVs in each stateroom
• TVs in main salon, galley, gym, aft deck
• Marantz NR1504 & SR7009 stereos
• Apple TV plex central ships audio
• Apple TV plex central ships video
• RTI entertainment system controlled through iPads

• Wolf 3-phase induction cooktop
• (3) Miele ovens
• Miele microwave
• Walk-in refrigerator in galley
• LG Inverter linear refrigerator
• Walk-in freezer in galley
• Hoshizaki ice maker in galley
• Nespresso and Jura coffee machines
• Milk frother
• 6-Slice Dualit toaster
• Dualit kettle
• Large preparation area
• Paco Jet ice cream machine
• Industrial vacuum pack machine
• Sous Vide immersion cooker

• (3) Gaggenau wine coolers- (2 in main hallway, 1 in skylounge)
• Propane barbeque, flybridge
• Large storage pantry, lower deck

• (2) Miele washing machines in guest area
• (2) Miele dryers in guest area
• Reservoir steam iron
• (1) Miele washing machine in crew area
• (1) Miele dryer in crew area

• (1) EPIRB
• (14) Rocket flares
• (3) Parachute flares
• MSOS Offshore pack defibrillator
• (6) Life rings

• Axis CCTV system
• Cameras- 2 in flybridge, side decks, forward mast, aft deck, owner's deck, 2 in engine room
• Monitors- flybridge, 2 in wheelhouse, Captain's cabin, crew quarters
• Security system/door alarms on main deck side doors and crew area
• Captain's safe

• (32) Smoke and (4) heat detectors
• Sea-Fire FM-200 H series in engine room
• Overhead sprinkler system
• Portable CO2, 3x5 kg
• Fire extinguisher (Powder 14x6 kg, 1x2 kg)
• Seawater firefighting- (2) fire pump 140 GPM @ 28 PSI (main & emergency)
• (4) Hose stations each with 15 meters of hose

• 17' Walker Bay with 70 hp Yamaha in garage
• (2) Viking 25-person life rafts

• (2) Sea-Doo Spark jet skis
• (2) Seabobs
• (2) E-Foils
• (2) Single Hobie pedal kayaks
• (1) Wakestate
• (1) Hyperlite wakeboard
• Double water ski consisting of a slalom and matching ski
• Inflatable beach club and swimming pool
• Various towables and float toys

• (4) Complete scuba sets with (8) tanks
• Dive compressor Brownie's XP25SF
• Snorkeling equipment for 20 passengers
• Miscellaneous fishing equipment

• Bar on every deck
• Ice maker on every deck
• 80 lb Hoshizaki on main deck aft

The Company offers the details of this vessel in good faith but cannot guarantee or warrant the accuracy of this information nor warrant the condition of the vessel. A buyer should instruct his agents, or his surveyors, to investigate such details as the buyer desires validated. Hours listed may vary from actual hours due to recent use. Purchaser is encouraged to verify hours prior to purchase. This vessel is offered subject to prior sale, price change, or withdrawal without notice.
