Length o.a.:

39m / 127’11”

Beam:

Draft:

Displacement:

Displacement

Gross tonnage:

241

Net tonnage:

72

Hull:

Three layers of planked laminated wood with two

layers of epoxy coated fiberglass

Superstructure:

Planked laminated wood with one layer of epoxy

coated fiberglass

Decks:

Teak

Naval Architect:

Mahir Besdas

External Designer:

J Kinder & Platinum Super Yachts

Internal Designer:

J Kinder & Platinum Super Yachts

Class:

RINA 100-A-1.1,Y

Commercial Classification:

Malta Commercial

Maximum speed:

16 knots

Cruising speed:

11 knots

Consumption (approx.):

250 lph @ 11 knots incl. generators (approx.)

Range:

880 @ 11 knots incl. generators (approx.)

Engines:

  Twin MTU M93 2400hp

Engine hours:

Port: 2290 / Starboard: 2290 (May 2016)

Generators:

1 x 55kw amd 1 x 65kw KOHLER

Generator hours:

Port: 5610 / Starboard: 5473 (May 2016)

Steering:

Propellers:

2 x 5-blade fixed pitch propellers

Gearbox:

2 x ZF Type 3060A

Fuel:

19000 l

Lubrication oil:

300 l

Fresh water:

3300 l

Black water:

2250 l

Bow thruster:

American Hydraulic

Stabilizers:

TRAC 370 digital zero speed

Fuel separator:

Alfa-Laval

Air-conditioning:

4 x Copeland Scroll 80000 BTU/hr reverse cycle

Toilet system:

JETS vacuum

Boilers:

3 x 100ltr 2 x 80ltr

Voltage:

220 V

Frequency:

50 Hz

Batteries:

24 volt DC/ type Gel for M/E, generators and service. Mastervolt battery charger

Compass:

1 x MX MARINE satellite compass

1x Plastimo M100 magnetic compass

Rudder Indicator:

VDU

Speed/Temp

Simrad Dopler speedlog DS-80

Depth sounder:

Simrad IS20

Radar 1:

  2 x Navico 6kw prossesors

  3 x Simrad glass bridge monitors

Electronic chart system:

2 x Simrad integrated network system

GPS:

2 x GPS Simrad GS10

Instrumentation system:

(wind speed & direction)

Simrad IS20 Wind data

Speed / Temp

Simrad Dopler speedlog DS-80

GPS

2 x GPS Simrad GS10

Navtex

Furuno NX-300

AIS

Simrad AI50

Chart Plotter

2 x Simrad integrated network system

Security Watch

BNWAS

Phones

Panasonic TDA – 100

Multimedia wireless network

VHF hand held radio:

1 x Simrad RS87 (2 x VHR-DSC stations)

SAT communication

DVK INMARSAT FLEET BROADBAND

Satellite Antenna

KVH Inmarsat

TV/ DVD:

SAMSUNG TVs & Pioneer DVD Players in all cabins

Satellite:

2 x Transvision antennas M9MV

Sound System

1 x Multi Rotel Amplifier

1 x Rotel Amplifier

Refrigerator:

2 x General Electric

1 x General Electric wine cooler

Freezer:

1 x Francesconi

1x Bosch fridge/freezer (crew mess)

Oven:

2 x Miele Ovens H4540B KAT and H4900B

Stove:

1 x Miele KM 5670 Electric burner range

Microwave:

1 x Miele M-8261

Icemaker:

1 x General Electric

Dishwasher:

1 x Miele GS 1312

Washing/Drying machine:

2 x Miele 1918 Commercial Type

2 x Miele 1565 Commercial Type

BBQ & Grill

On flybridge

Bar

On sundeck

Anchor windlass:

2 x Muirl 6000 electric vertical with controllers

(380 VAC 3-phase)

Aft warping capstan:

2 x Muirl VRC 6000 (hydraulic)

Chains:

2 x 5 lengths galvanized studlink each 137.5mm/16 diameter

Anchors:

2 x Hall 250kg INOX 316L

Passarelle:

Besenzoni Hydraulic telescopic 5mt 2-stage

Swimming Platform

Hydraulic

Underwater lights

10

Jacuzzi:

Sundeck

Tender:

1 x Novarania 540QL tender with inboard 220hp Volvo Penta D3

2 x Yamaha Waverunners – FZS 1800ac with reverse gear

 Toys:

1 x Seabob

4 x Donuts

1 x Jetlev

1 x Hoverboard

1 x Flyboard

1 x Set of water skis

Sun loungers

EPIRB:

Simrad 406 MHZ Auto

Life rafts:

3 x Plastimo transocean (12 pers) SOLAS

Life jackets:

24 x Adult, 6 x Children, 4 x Life rings with lighted

buoy, 2 x Bridge life rings with light & smoke

signals

Search & Rescue Transponder:

1 x Simrad SA50 Rescue Sart 9GHz

Fire–fighting equipment:

1 x 2kg Dry powder fire extinguisher

Fixed Systems:

C02 E/R permanent firefighting system

1 x 18kg CO2

Fire axes & blankets

1 x 2kg Dry powder

1 x fire suit

18kg x 6kg Dry powder

9 x 5kg CO2

1 x breathing apparatus

Immersion suits:

15

Alarms

SEA TEC fire alarm system

Security

6 x CCTV system with monitors on bridge and crew

mess

Ships safes:

1 x Master cabin

1 x VIP cabin

1 x Captains cabin
