The varnished teak transom, Flag Blue Awlgrip hull, Light Cream Gelcoat deck, Cream Awlgrip single boot stripe

and green bottom make this boat look stunning. Stainless steel bow rails, varnished teak toe rail and cockpit coamings?along with varnished teak handrails give the boat a great balance of looks and functionality. The deep, teak sole cockpit?with forward and aft-facing seating has a walk-through transom door to the swim platform. Wide side decks with integral?fender storage, properly placed handrails and bow rail, and a huge foredeck locker makes handling lines/fenders easy?and safe for docking.

?

• Flag Blue Awlgrip hull paint (2014)
• Light Cream gelcoat deck and cabin top, with molded-in nonskid.
• Single Cream Awlgrip bootstripe
• Green bottom paint
• Varnished teak transom
• Gold leaf name and hail

?

?

Construction:?

The hull is the Hinckley DualGuard? Composite Construction- Kevlar?/E-glass outer skin with balsa and Corecell? core and Carbon fiber inner skin, infused with Vinylester resin using Seaman Composite Resin Infusion Molding Process?(SCRIMP?). The deck is E-glass skin with balsa and Corecell? core, laminated with Vinylester resin using Seaman?Composite Resin Infusion Molding Process (SCRIMP?). These materials and building techniques provide for a superior surface finish, greater resistance to osmosis, high degree of stiffness & stiffness/weight ratios, greater hull strength against impact damage, and thermal insulation. Thru hull fittings are non-metallic composite with ball-valve seacocks below waterline and above the waterline where appropriate. Bronze seacocks, thru-hull fittings and sea strainers on propulsion engines. Rub rail has stainless steel half-round on fiberglass molding. The swim platform is painted to match hull color with teak decking inserts and stainless-steel half round with a stainless-steel telescoping 3-step swim ladder under swim platform.

?

• Hydraulic Muir windlass - mounted in custom anchor well.
• Custom 316L stainless steel bow roller for primary anchor.
• 55-lb Delta primary anchor with 200' x 3/8" HT chain rode.
• 40-lb Fortress FX55 Secondary: anchor with chain and rope rode
• Anchor locker molded into the foredeck, with hinged and gas-spring assisted hatch.
• Anchor windlass control at helm station
• Remote control for anchor windlass
• Saltwater deck wash and freshwater spigot located in foredeck locker.
• (2) JL Audio waterproof cockpit speakers - controlled from main system.
• Courtesy lighting under cockpit coaming.
• Safety light on cockpit step.
• Cockpit shower with hot/cold mixing valve with shower near transom door.
• Dockside water supply inlet and shore cable TV/phone inlet.
• Sunbrella navy cockpit cushions
• Lockers under cockpit coamings port and starboard.
• (8) portlights (all opening) with screens.
• (9) opening overhead hatches with stainless steel frames provide a light and airy interior.
• Oceanair Skyscreens provide bug screens/shades on all overhead hatches
• Powered Ocean Air Skysol pleated shades on pilothouse side windows
• Custom detailed Onyx or Corian countertops in galley and heads.
• Custom rheostat cabin lighting throughout provides enhanced ambiance.
• Two custom step lights
• Custom pop-up cleat on swim platform - acts has a handrail for swim ladder.
• 30" high 316L stainless steel bow rail
• Molded non-skid surface on side deck and cabin housetop walking surfaces.
• Smooth gelcoat surface on vertical surfaces of deck, house, waterways, and pilothouse top
• Tapered varnished teak toe rails with Hinckley profile.
• Custom varnished teak name lantern boards with running lights on pilothouse roof sides
• Varnished teak molded eyebrow molding around cabin top.
• Varnished teak handrails are mounted on forward cabin top and along the top of pilothouse roof, port and starboard.
• Custom painted teak side handrails under the port and starboard pilothouse roof match the deck.
• (4) custom varnished teak dorade boxes on trunk cabin with polished stainless steel cowl vents with Broan closures in accommodations.
• (2) Open custom Hinckley stainless steel open bow chocks
• (4) Closed custom Hinckley chocks.
• (10)316 stainless steel mooring cleats bow, stern and spring line cleats
• Bow and stern cleats are 12" and spring line cleats are 10"
• (5) Smoke gray tint hatches with stainless steel frames & Skyscreen screens & blinds.
• Overboard direct drainage scuppers for cockpit.
• Custom Hinckley fender storage lockers alongside decks
• Wichard folding pad eyes and chafe strips for fender and dock lines near stern cleats.
• Huge foredeck locker w/outboard motor bracket and lashing for inflatable dinghy.
• Custom Hinckley aluminum mast and 2 antenna domes for all boat antennas
• Teak bow burgee pole with flush socket.
• Stern mounted 4' varnished teak staff with flush socket.
• Dock lines
• (4) Fenders

?

?

?

COCKPIT:

?

Entry to the boat is from either port or starboard or through the transom gate on the starboard side of the swim platform. Molded fiberglass boarding steps are inboard of the cockpit coaming port and starboard. The cockpit sole is teak and the coaming is varnished teak. A comfortable settee aft that folds up and stores away completely and additional aft facing seating port and starboard of the pilothouse door provide a great area for entertaining. The cockpit sole hatch with recessed hinges has manual hydraulic risers for access to the engine, and there is fender storage on the underside of the hatch. Two Glendinning powered shore cord reels exit the transom through a flush hatch.

?????????????????????????????

?

PILOTHOUSE (Amidship):

?

Entry to pilothouse from the cockpit is through polished stainless steel framed, full height, curved, green tinted tempered glass doors. These custom doors have six panels (each side has one fixed plus two sliding, port and starboard), allowing several opening positions up to 64 inches wide, which makes the interior feel open and airy. All fixed windows are laminated safety glass, and the three forward fixed windows have windshield wipers & washers. There is an opening side window to starboard. The side windows have an electric Ocean Air Skysol roman-style blind system, and the forward windows have outside snap on off white Textiline fabric shade covers. The pilothouse aft door has roman style shades. Overhead? lighting is provided by halogen lamps on dimmer circuits, and additional lighting is provided by wall-mounted lamps.

?

A large U-shaped dinette to starboard surrounds a varnished cherry table with custom compass inlay, which can be lowered to convert to a double berth. To starboard are two custom Thomas Moser cherry chairs on either side of the custom cherry cabinet which holds the entertainment center, and a 42? Plasma television with HDTV satellite receiver is concealed in a cabinet outboard and raised with an electric lift. The Bose Lifestyle 28 surround-sound audio system has an XM radio receiver. A bar area with storage below is all the way forward to port, and a built-in chart?drawer is in the top.

?

The helm is forward and to starboard, with twin adjustable helm seats. Navigation electronics are installed for ease of use and service. A companionway forward leads below decks to the galley and staterooms. The pilothouse is finished with gloss-varnished cherry including dash and bar area, and the varnished teak and tulipwood pilothouse sole has removable protective covers. Upholstery is tufted Spinneybeck Blue dark leather with custom sliced antler buttons. The twin Moser cherry chairs are upholstered in matching Spinneybeck Blue leather, and there are padded Spinneybeck Blue leather tops on the helm pod, entertainment center and bar top.

?

?

?

?

HELM area:???

?

The Helm is forward to starboard in the pilothouse, and has and has two Stidd helm seats covered in Spinneybeck Blue leather. The Helm seats are electrically powered to move up and down as well as forward and aft. The dash is satin varnished cherry, and the outboard shelf has Blue leather pod surfaces where electronics are mounted. This area also has the Hinckley JetStick?, engine controls, navigational instruments, engine gauges, and a teak-rimmed steering wheel.

• The foot well at helm station is 5" higher than pilothouse sole for improved visibility.
• Varnished cherry mug racks are port and starboard of the helm.
• Varnished cherry binocular box.
• 110-VAC outlet.
• JetStick? system - includes manual override back-up.

Galley?(Port):?

?

Down several steps from the pilothouse, the U-shaped galley is to port. This area is open above to the pilothouse and receives additional light and ventilation from the opening port and overhead hatch. There is ample storage for crockery, supplies and provisioning in drawers and lockers.

?

The double stainless-steel sink is aft facing, and outboard of it is a countertop accessed storage bin. The countertop has a back lip here that protects the cherry bulkhead. Over the sink is fitted rack for dish storage. The microwave/convection oven is flush mounted over the sinks. Below the sink is a storage space accessed through two hinged doors.

?

Outboard is the two-burner electric cooktop with storage drawers under and storage lockers outboard, and the twin drawer refrigeration/freezer system with cherry joinery. There is additional counter space with storage below and over,?and a door to access the trash can and recycle bin.

?

• Corian Magna Sahara countertop with custom edge details.
• Seaward 2-burner electric cook top.
• Sharp Stainless-steel microwave/convection oven - flush mounted above sink.
• Trash compactor
• Double polished stainless steel undermounted sink with Grohe single-lever fixture with sprayer
• Hot and cold pressure freshwater system
• Instant hot water system.
• (2) Subzero 700TCI Refrigeration and Freezer/icemaker drawers with cherry-faces
• 110-volt AC icemaker in a locker below the companion helm seat
• Additional 110-VAC outlets are positioned for coffee maker and toaster
• Over-counter lighting with dimmer
• Storage for dinner service for 8
• Inboard locker in galley has adjustable shelves, pass-through doors on pilothouse side

?

Guest Cabin:

Across from the galley to starboard, the guest cabin is entered through a pocket-style door. This cabin has two twin berths, one forward and one aft, covered with Sunbrella covers. There is drawer storage under the berths and a hanging locker and dresser between. Locker storage is at the head of each berth and also at the foot of the forward berth.

?

Features include:

?

• 110-volt outlet.
• Overhead lighting on dimmer.
• Bulkhead mounted lighting.
• Reverse cycle AC/heat vent.
• Honey Onyx stone dresser top.
• Two flush-mounted speakers.

?

?

Guest Head:

?

The guest bath is forward of the galley to port and is finished in varnished cherry including lockers and mirror trim and has with a light cream gelcoat molded sole for easy cleaning.

?

Features include:

?

• Corian Magna Sahara countertops with undermounted stainless steel sink with Grohe single-lever fixture.
• Sealand VacuFlush marine toilet plumbed directly to 100-gallon holding tank. The holding tank can then be emptied via a deck fitting or overboard through the Sealand macerator pump to a discharge facility.
• Stall shower with Lucite doors, with a Grohe single lever mixing valve
• Opening portlight
• Overhead lighting has dimmer except for shower.
• Storage areas are outboard and under sink.
• Custom towel racks.

?

?

?

Utility Center & Storage Area:?

?

To starboard, forward of guest cabin, is a large storage area with double cherry doors. This area serves as a utility center and houses the ASKO front-loading full sized washer and dryer, plumbed to the sump tank. Also built-in here is the Sea-vac central vacuum system, a hanging locker, and additional storage compartments.

?

?

?

Master Suite (Forward):

?

The full width master stateroom all the way forward is quite luxurious. Entered from the companionway through a solid cherry door, this stateroom has a centerline forward-facing queen berth with storage drawers below. A desk is centered on the forward bulkhead, and dressers with Honey Onyx stone countertops are port and starboard of it. A plasma TV is bulkhead mounted over the desk and facing the bed. A custom Thomas Moser desk chair and the padded headboard are covered in tufted Spinneybeck Blue leather. Moving aft there are cedar lined hanging lockers port and starboard?and a small settee to port by the bath door.

?

Features include:

• Ample storage in lockers and drawers port and starboard.
• Built-in desk/vanity.
• Custom finished Navy-style portlights.
• Overhead lighting on dimmer circuit.
• Bulkhead mounted lighting forward and aft.
• Custom halogen swivel art lighting over the owner's bunk to illuminate anything mounted on bulkhead.
• Reverse-cycle AC/heat vents
• 32" LED TV/monitor with HDTV satellite TV receiver, and stereo speakers.
• Bose Lifestyle 28 surround-sound audio system with XM satellite radio receiver.
• Queen innerspring mattress
• Built-in desk/vanity on centerline
• Thomas Moser cherry chair with Spinney Blue leather cushion slides under vanity/desk for storage.
• Desktop/vanity has a custom leather inset and lifts up and has mirror on back side.
• Samsung TV/monitor with HDTV satellite TV receiver, connected to shore cable.
• Surround audio system and separate satellite radio receiver.

?

?

?

Master Head:

?

Aft to port in the master stateroom is the entry to the ensuite bath. This bath, featuring a separate stall shower, vanity, and marine toilet and is also finished in varnished cherry.

?

Features include:

• Custom Honey Onyx stone countertop with custom edge details with custom polished chrome-plated hammered
• copper sink with Grohe single-lever fixture.
• Separate Stall Shower with a Grohe single lever mixing valve.
• Sealand Vacu-flush marine toilet plumbed directly to 100-gallon holding tank.
• The holding tank can then be emptied via a deck fitting or overboard through the Sealand macerator pump to a?discharge facility.
• Opening portlight.
• Full-length mirror on head door with cherry trim.
• Overhead lighting has dimmer except for shower.
• Storage areas outboard and under sink.

ELECTRICAL SYSTEM:

?

• 120/240 volts AC

• 24 volts DC
• Two Glendinning powered shore cord reels
• Custom lighted circuit breaker panel w/smoked glass cover, meters, switches, and indicator lights
• Common wire bonding with a minimum branch wire size of #8 AWG per ABYC.
• Start batteries: Four (4) BCI group 31 AGM batteries for main engines and generator
• House service: Four (4) BCI group 31 AGM batteries for the main house bank
• Heavy-duty battery switches for port and starboard engines, with ability to parallel start batteries
• (2) 100 amp 24 volt DC.Balmar alternators
• (2) 24-volt DC battery chargers.
• 240 volts AC from shore with 12-volt DC electronics panel
• 12 Volt lighting
• (2) 120/240 volts AC Power 50-amp inlets
• Custom 12-volt cockpit outlet - under stbd forward teak coaming.
• Link 10 battery monitor
• Generator -Westerbeke 240 volts AC 12 kW generator Model 12 OBTDC in sound shield (2709 hrs. May 17?)
• Remote panel with gauges for generator starting

.

?

?

?

MECHANICAL EQUIPMENT & ENGINE DETAILS:?

?

• Twin 2004 Man D2842LE404 diesel engines with 2028 hours and MAN service intervals completed
• Foam/composite engine room insulation with metal covering on visible surfaces.

• (2) Hamilton 403 water jets
• Hinckley JetStick system-integrates forward and aft motion of boat, steering, and bow thruster into single joystick.
• Twin Disc MG-5145SC transmissions, starboard transmission was rebuilt 2012
• Double gaskets on access door to engine room.
• Engine Air Intake: Air De-misters at both vents. Baffled and insulated.
• (4) cage-protected lights.
• Fireboy fire suppression system with automatic engine shutdown.
• Alarms for low engine oil pressure, engine high water temperature
• Racor fuel-water filters with pressure gauges, water sensors, petcock and drain tubes.
• Racor in-line fuel/air separators.
• Baffled and insulated engine air intakes with air de-misters at both vents.
• Underwater exhaust system - with low-speed by-pass.
• Side Power hydraulic bow thruster.
• Dual-cylinder stainless steel trim tabs.
• Power-assist steering.
• Oil Transfer Pump - reversible, 24-Volt DC - for main engines, transmissions, and generator.
• A custom 5-gallon oil reservoir in engine room is plumbed to the oil transfer pump.
• Fresh hot and cold pressurized water,
• 24-VDC main and back-up pumps supplying Galley, Shower, Head and Cockpit shower.
• (2) Automatic 24-volt DC sump pumps for showers, washing machine and air-conditioning condensate.
• (4) Rule? 24-volt DC electric 3500-GPH bilge pumps with ULTRA automatic float switches.
• Highwater bilge alarm
• Saltwater deck wash deck wash pump with hose connections on deck near anchor roller.
• 17-gallon water heater - marine insulated stainless-steel heater.
• 100-gallon aluminum holding tank
• 200-gallon stainless steel freshwater tank
• Marine Air Systems reverse-cycle marine air conditioning - one 24,000 BTU "chilled water" system with four (4) separate air handlers for the salon, galley and heads, guest cabin and owner's stateroom.
• Washer and dryer
• Central vacuum system.

• Fireboy fire suppression system with automatic engine shutdown.
• (4) Fire Extinguishers: 2-lb. Type B-1 fire extinguishers for class A, B, and C fires.
• Remote controlled spotlight - on pilothouse roof.
• Aft-deck flood light mounted on mast.
• Horn - Kahlenberg 24-Volt DC dual-trumpet air horn with switch at helm.
• Searchlight - 24 Volt-DC with remote at helm
• (10) Life jackets - (8) adult and (2) children
• Navigation lights
• Coast Guard safety package

The Company offers the details of this vessel in good faith but cannot guarantee or warrant the accuracy of this information nor warrant the condition of the vessel. A buyer should instruct his agents, or his surveyors, to investigate such details as the buyer desires validated. This vessel is offered subject to prior sale, price change, or withdrawal without notice.
