MAIN SPECIFICATIONS

Length Overall: 150' (45.72m)

Length at Waterline: 139'9 (42.59m)

Beam: 28' (8.53m)

Min Draft: 7'10" (2.39m)

Max Draft: 8' 10" (2.69m)

Year Completed: 2005

Model Year: 2005

Refit: 2022/2024

Type: Motor Yacht

HIN: 0018

Tonnage: 416

Displacement: 266.87 LT (long tons)

Hull Config: Semi-displacement

Guests: 12

Crew: 9

CONSTRUCTION

Builder: Christensen

Naval Architect: Christensen Shipyards, LLC

Exterior Design/Stylist: Setzer Design Group/Fernando Torres

Interior Design/Stylist: Pavlik Design Team/Fernando Torres

Hull Material: GRP

Deck Material: Teak

Classification: AMS ABS

SPEED

Maximum: 18 knots

Cruising: 13 knots

Economical: 10 knots

Range: 2000 @ 12 knots

Consumption @ Max: 145 US gallons p/hr

Consumption @ Cruising: 124 US gallons p/hr

Consumption @ Economical: 52 US gallons p/hr

CAPACITIES

Fuel: 9,312 gallons / 35,249 liters

Water: 1,500 gallons / 5,678 liters

Grey Water: 499 gallons / 1,899 liters

Black Water: 1,447 gallons / 5,477 liters

Lube Oil Capacity: 150 gallons / 567 liters

Waste Oil Capacity: 150 gallons / 567 liters

CLASSIFICATION & CERTIFICATIONS

Flag: Jamaica

Classification: AMS ABS

MACHINERY

MAIN ENGINES

Engine Type: 2x Caterpillar C-32 ACERT Diesel

Horsepower: 2x 1900

Engine Serial Numbers: Port - RPM01139; STBD - RPM0114

Main Engine Hours (Port): 122

Main Engine Hours (Stbd): 122

GENERATORS & ELECTRICITY

Output: 380 Volt 50 HZ 3-phase

Generators: 2x Caterpillar 85 kW - turbo-charged (Gen # 1 & 2) & 1x Caterpillar 50 kW - naturally aspirated generator (Gen #3)

Generator Fuel Consumption: 85 KW - Turbo charged generator consumption = 7.4 Gal/ hr or 28.1 Lit/hr

50 KW - Naturally aspirated generator consumption = 5.2 Gal/hr or 19.7 Lit/hr

Generator #1 Hours (85kW): 27,923

Generator #2 Hours (85kW): 9,490

Generator #3 Hours (50kW): 9,781

Shore power: Atlast Marine Systems, Inc - Model SPA-90F

Generator Starting: 24 VDC

BATTERIES

Batteries: 4x 8D AGM

Generator Starting: 4x 8D AGM

Emergency: 8x ODX - AGM-31M

PROPULSION & STEERING

Drive: Shaft propeller

Gearboxes for Main Engines: ZF BW46S

Stabilizer: Quantum ARC 3000

Stabilizer Underway: Yes

Stabilizer at Anchor: Yes

Steering System: Anschutz

Emergency Steering System: Jastram

Helm Control: Jastram

OTHER MACHINERY

Water Makers: Blue Water Explorer

Bow Thruster: American Bow Thruster

Fuel Separator and Filtration: Alfa Laval MAB 103B/Racor Filtration

Sewage System: Headhunter Tidal Wave HMX MSD-Type II

Fresh Water System: 2x Headhunter Mach 5

Oily Water Separator: BilgeMon 488

Air Compressor: 7 Bar / 100 PIS

Air Conditioning: 380,000 BTU Titan Air

COMMUNICATION AND NAVIGATIONAL EQUIPMENT

SAT COM: SeaTell (Internet) / Starlink RV Internet

Satellite TV Systems: Nova

Telephone System: Panasonic PABX

SSB: Furuno FS-1570

VHF: 2x Furuno FS-1570

Cellular Phone System: GSM

Intercom: Raytheon ray 430 Loudhailer

Iridium: Thrane/LARS LT-3100S

Navtex: Furuno NX-700

Radar: 2x Furuno 9 GHZ FR- 2115-B w/ ARPA

Gyrocompass: Anschutz

Magnetic Compass: Cassens & Plath

Auto Pilot: Anschutz

Depth Sounder: Furuno color LSD FCV-1200L

GPS: Furuno GP1871 F/Koden KGP-902

AIS: FA-150

Ships Computer: HP

Ships Printer: HP Office Jet Pro 9125e

Plotter: Nobeltec TimeZero

Wind/Speed Log: Simrad

Telefax: Fleet 77

Weather Fax: Furuno DFAX-207

ENTERTAINMENT SYSTEMS

Video Equipment: Crestron Remote Multi-system

TV's: Samsung Smart TV's throughout

Audio Equipment: Chameleon 64i/Denon/Arcam

DVD's: Sony

CD Player: Yamaha

iPod Stations: Apple iPod stations throughout

Misc.: (6) Blu-ray/Apple Tv/Apple mini

GALLEY & LAUNDRY EQUIPMENT

MAIN GALLEY EQUIPMENT

Cooktop: AEG 5 burner electric

Oven: 2x Miele

Microwave: 1x Sharp/1x GE

Refrigerator: 4x Liebherr

Freezer: 4x Liebherr Freezers

Additional Refrigerator/Freezer: 1x small fridge - Norcold

Dishwasher: Chef-King 50

Wine cooler: Phiestina

Icemakers: 2x Electrolux

CREW GALLEY/ MESS

Dishwasher: 1x Bosch

LAUNDRY

Washing Machines: 3x Speed Queen

Dryers: 3x Speed Queen

DECK EQUIPMENT

Anchor Windlass: 2x Muiri

Deck Capstans: 2x Maxwell 3500

Anchors: 2

Anchor Chain & Rode: 150 m x 2

Boat Crane and Davits: Nautical Structures HMC-1100 & Nautical Structures HMC-4000

Passarelle: Besenzoni

Accomm Ladders: 1x portable

Swim Ladders: 1x Stainless Steel w/ teak steps

Exterior showers: 2x on swim platform

TENDER & TOYS

Tender: 16' Nautica Yamaha 70 4-stroke

(2) Waverunners: (2) Yamaha 1200 CC

(2) Kayaks

Note: Subject to change and/or negotiation during the buying process.

SECURITY, FIRE FIGHTING AND SAFETY EQUIPMENT

SECURITY

Cameras: 6

Monitors: 8

Fire/Heat/Smoke Detectors: New Tyco System - throughout

Fixed FM 200 System: 1

Portable CO2: 5

Fire Extinguishers: 36

Seawater Firefighting Station: 6

Life Rafts: 4x Viking 12-persons in canisters/hydrostatic release

Life Rings: 5

EPIRB(s): 1x 406 MHZ Automatic/Manual ACR GlobalFix V4

SART: 2x ACR Pathfinder Pro's

Flares: Handheld, orange smoke, and parachute flares

ACCOMMODATION AND LAYOUT

12 guests in 6 cabins

9 crew in 5 cabins including captain's cabin

REFIT 2021/2022

Machinery

● New Caterpillar C-32 ACERT 1900 HP

● Caterpillar Generators - x2 85kw, x1 50kw

o New long blocks and rebuilt electrical power packs

● AC System: The system was replaced by Titan Marine: Chillers, air handlers, and plumbing

● Atlas System: Refurbished 2021

● Hydraulic system - Overhauled: PTO's were rebuilt, new hydraulic hoses and intercoolers were rebuilt

● Stabilizer system - Overhauled: Pump and hydraulic motor rebuilt

● Freshwater system- Pumps replaced

● Waste Treatment system- NEW

● Diaphragm pumps - Overhauled: All pumps were rebuilt

● Exhaust system: NEW DeAngelo's

● ER plumbing: Overhauled

Exterior

● The bottom was soda blasted at Roscioli (2020) with a new barrier coat applied, and the bottom paint was applied by compressed air spraying.

● Running gear (2020): Stabilizer seals, shaft seals, rudder shaft seals, and cutlass bearings were replaced.

● Through hulls were all replaced or serviced.

● All overhead panels on the main deck, bridge deck, and sundeck were repainted

● All Countertops were replaced

● The Foredeck non-skid was repainted

Interior

● The interior of Ionian Princess was completely reimagined in collaboration with the owners and Yacht next. All items listed are newly installed.

● Headliners throughout

● Interior furniture

● Carpet throughout

● Custom bedroom furnishings in all staterooms

● New wall finishings in all staterooms and ensuites

● Interior lighting was converted to LED

● Pilothouse - helm chairs and settee reupholstered

● Captain's cabin - modernized

● Crew quarters - modernized

● Galley - All new cabinetry, countertops, lighting, and refrigeration

REFIT 2023/2024

Machinery

● Main engine overhaul / manufacturing certification

● Main engine block heaters installed

● 3 x generators serviced and reconditioned

● Air-conditioning systems and plant reconditioned

● Air-conditioning insulation renewed chill water loop

● New Tyco fire system installed

● Alfa Laval fuel polishing system reconditioned

● Bow thruster inspection and calibration

● Engine Room CO2 inspected and reconditioned

● Emergency fuel shut-off system upgraded

● New fire pump installed

● AC Bilge pumps reconditioned

● Emergency fire / bilge pumps reconditioned

● Sundeck and bow cranes rebuilt and reconditioned

● Tanks inspected, and new sensors installed

● Windlass & anchors removed and reconditioned

● Oily water calibrated and reconditioned

● Stabilizer rams & control heads reconditioned

● Steering systems reconditioned

● Thru-hulls replaced throughout the vessel

● New valves installed in engine room

● Grey water pumps rebuilt & headhunter auto pumping installed

● Atlas power unit reconditioned & new cooling system installed

● New emergency battery banks installed

● New main engine & generator batteries installed

● Electrical systems reconditioned

● GMDSS equipment was reconditioned & new iridium installed

● Exhaust systems inspected

● Running gear inspection

● Sea chests - fiberglass tubing replaced

● New zincs installed

● Rudders & propellers - new prop seed coating

● Bottom paint - touched up

● Bridge windows re-sealed

● Prop crack test - passed

● Rudder bump test - passed

● Bow thruster grates reconditioned

Exterior

● All watertight doors & hatches reconditioned

● Exterior overheads - Velcro replaced & mounts replaced

● Deck stanchions - New gaskets & remounted

● Non-Skid redone all 3 decks

● Varnish on cap rails recoated

Interior

● Interior overheads - Velcro replaced & mounts replaced

● Twin cabin mirror replaced

● New smart Tv's installed

● New Apple TV's installed

The Company offers the details of this vessel in good faith but cannot guarantee or warrant the accuracy of this information nor warrant the condition of the vessel. A buyer should instruct his agents, or his surveyors, to investigate such details as the buyer desires validated. This vessel is offered subject to prior sale, price change, or withdrawal without notice.
