Sails and Rigging

• Sparcraft aluminium mast with single spreader and Dyform wire rigging with Harken Battcar track C-system?
• Sparcraft aluminium crossbeam and longeron with self-launching bow roller starboard side for spare anchor
• Sparcraft aluminium boom with fishbone boom upgrade
• Harken - 2 x 50 electric winch (Jib Sheet, Reefs) at helm
• Harken - 1 x 50 electric winch (Main Halyard & Mainsheets) at helm
• Harken - 2 x 46 electric winch (lifting dinghy, dagger boards and/or spinnaker and Code 0) aft end coaming?
• Harken Size 46 electric winch on port deck (spinnaker & Code 0 halyard)
• Jib furling unit, manual Profurl C430.
• Ullman Mainsail cloth upgrade to ASDL tri-radial cruising sail?(standard cut sail)
• Ullman Headsail upgrade to ASDL tri-radial cruising sail
• Ullman Code 0/Screecher in CZ fabric (includes deck hardware excludes winch)
• Line bag package
• Assym Spinnaker includes deck hardware?
• Assym spinnaker logo?
• 225 sq m Parasailer
• Seadek - Aft cockpit - Terra (excludes the 2 x transom steps which are now painted non slip)
• Carbonautic Steering Wheel - black?
• Carbon dock line chafe plates x 10?

Engines, Drive Units and Props

• 2 x Yanmar 4JH45 x SD60 (45hp) diesel engines and standard C25 engine control (Less than 300 hours on each engine)
• Each engine fitted with a 70A/24V auxiliary alternator for charging house bank?
• Integrel ADVANCED TECHNOLOGY Charging System on both engines
• Dual Racor fuel filters for each engine
• Electronic engine Throttles (midway mounted single position)
• 2x Bruntons Varifold ?3 blade 19" x 15" folding propellers. Propspeed on propellers, fresh Dec 2025
• Each engine fitted with a 70A/12V auxiliary alternator for charging engine batteries?
• Dual Racor fuel filters for each motor
• Fuel transfer pump and fuel polishing?

Generators

Integrel?is classified as an "extra low voltage DC system" and falls within the scope of the international standard ISO 10133:2017 and ABYC E11

Integrel?is a modern, intelligent way of generating, storing, and distributing electrical energy in off-grid applications, such as recreational marine craft, without fitting a standalone generator with a second engine. It?s completely automatic, delivering significant amounts of energy seamlessly throughout the vessel without user input. It?s fuel-efficient, reducing overall fuel consumption for propulsion and generation, and very cost-effective with virtually no maintenance costs. Integrel completely replaces a conventional generator and delivers all the power that you need to make living on board as comfortable as living at home.

Dual Integrel?Systems

Alcyon has 2 propulsion engines and a dual?Integrel?system. With one generator on each engine and with 2 Intelligent controllers.

The advantages of a Dual Integrel System:

Double the charging capacity (18kW).

Half the battery charging time.

Redundancy in the case of a single engine failure, electrical fault or if there is a problem?with either?Integrel system.?

Batteries

• House bank: 4ea 200-amp 24v batteries wired as 48v@400-amp Victron Lithium batteries, 1x 24v Victron Lithium, 1x 12v Victron Lithium?
• 1 x Victron Multiplus 24v /110v 3000-watt inverter/70A charger, 1x Quattro 5000-watt 48v charger inverter, 12
• 2 x 12 V AGM start batteries?

Interior

• Two electric toilets
• 2 x Vitrifrigo DW180A multi temperature 2 drawer fridge /freezer unit (4 draws in total)
• Electric plugs one in each cabin, two at nav table, two in galley and two above fridge area?
• 12V Outlet at the nav table.
• USB sockets and plugs in each cabin and nav station
• Shore power cable; 20m 32A Marinco with easy lock system starboard transom step with US dock side plug, 120v/220v cables
• All lighting Marine - LED including service areas?
• Courtesy lights (blue) one on each transom step and one in each companionway?
• Mattresses 150mm (6") thick and headboards for each cabin
• Heads counter tops, Solid surfacing with Corian basin all cameo white with towel rails in all heads
• All Cabins have white Oceanair pleated shades
• All heads and showers have Oceanair white roller shades
• Samsung Washer/Dryer - 230V ?
• 1x extra Vitrifrigo DW180A multi temperature fridge /freezer (total of 2 drawer fridge combo units)
• Rainman 30 gph 120v watermaker
• Spectra Z-ion protection system for Fresh Water system
• Aircon 1x Frigomar 16 BTU & 3x 10BTU (Full house) sharing pumps (variable speed inverter tech)
• 1x Caframo Marine fan situated on either side of the head-bunk panel ie 2 per cabin?
• Telescopic table with double fold out leaf for cockpit that converts to a bed incl cushion (cockpit)
• Upgrade to Smeg 220V 60cm 4 plate induction cooker top
• Avonite solids to cabin/hull counter tops
• Samsung Smart FHD 32" color TV with swivel wall mounting bracket for saloon
• Oceanair Saloon Blinds colour white?

Electronics

• Raymarine AXIOM 12", Multi-function 12" w charts
• Raymarine Quantum Q24C 18" Radar?
• Raymarine i70s Colour instruments DST tri-ducers, 2x at lower helm, 2x at upper helm
• Raymarine Evolution Autopilot with p70s control head & ACU-400, EV1 Sensor Core, 1 each lower/upper helm
• Raymarine Type 2 Long Shaft electric Linear Drive
• Ray53 VHF Radio
• Raymarine AIS 700 send / receive system
• Raymarine - upgrade 9" MFD to 12" (fitted at lower helm)
• Iridium Go 9560 SATELLITE (sp) COMMUNICATIONS with Antenna on mast
• Poynting Wi-Fi omnidirectional aerial with Peplink Pepwave router
• Starlink
• 4 x ?400w Sunpower Solar Panels on cockpit roof with individual?charge controllers?

Dinghy

• 3.1m Highfield (white) in Hypalon with 15hp 2 stroke?
• Dinghy cover in same colour as the stackpack (custom made in Sunbrella by Ullman Sails)
• 15hp 2 stroke Yamaha?

Exterior

• 11 x Alloy 330mm mooring cleats - (includes anchor and transom cleats)?
• Aluminium stanchions with Dyneema double line guard rail ??
• Open mesh trampolines?
• Aluminium pulpits with seat
• Handrails on transom coaming?
• Stowage for life raft in cockpit?
• Cockpit cushions (75mm foam) covered in Sunbrella
• Outside Shower with hot and cold water - starboard transom
• Maxwell windlass HRC10 non-capstan version, foot switches on foredeck,
• Main anchor Rocna 33 with 50m of short link DIN766 G40 10mm galvanised anchor chain and 50m 3/4 line
• Foldaway swim ladder starboard transom
• Saltwater deck wash located on transom, fresh water at anchor locker
• Telescopic table with double fold out leaf for cockpit that converts to a bed incl cushion (cockpit)
• Telescopic table with double fold out leaf for saloon that converts to a bed incl cushion (saloon)
• Sunshade Awnings for cockpit ?includes built in composite track
• Switch and chain counter at helm for windlass Maxwell AA560
• 4 x ?400w Sunpower Solar Panels on cockpit roof with individual regulator?
• Secondary anchor, Fortress FX-37, 9.5 kgs with 3m of 10mm chain and 90m of rope ?
• Epoxy Barrier Coat + 2x coats of antifouling, fresh as of dec 2025, Island 77 plus
• Seadek - Aft cockpit - Terra (excludes the 2 x transom steps which are now painted non slip)
• Carbonautic Steering Wheel - black?
• Carbon stanchions x 12
• Carbon dock line chafe plates x 10
• Fishing Rod holders x2?
• Forepeak sail/rope hanging rails x 2?
• Adjustable surfboard/fishing rod straps under coach roof?
• Cockpit enclosure ?with clear and flexible glass side panels for lower helm and cockpit?
• Cockpit fridge under lower helm seat
• Viking Rescyou ocean 6UKL 6 man valise life raft?
• Custom helm seat upgrade - no 3rd pole?
• Extra switch at upper helm for Stbd aft winch?
• Port aft shower wet clothes bar?
• Bamboo saloon table upgrade cost - with flaps - no fiddles - 3" rounded corners?
• Bamboo veneer upgrade?
• 3rd electric winch at upper help position?
• Open shelving with alluminium frame where drinks cabinet is usually

Miscellaneous

• Relocation of the instruments at the nav table - move to Stbd inside hull
• Plug outlets and USB - C = behind drawers and inside of cabinets - Corian grommet?
• Owner supplied printer on shelf fitted in the middle of inboard nav cupboard?
• Owners supplied Sunbrella fabric cockpit cushions
• Cupboard latches on top and bottom of all cupboard doors (not on sides)?
• No waterfall edge on island unit Avonite - vertical grain bamboo & vertical grain bamboo instead of geometric fabric triangles?
• 110V and 220V boat?
• Fwd cabins - Bamboo top at aircon unit - white Avonite dressing table top?
• Owner supplied galley tap?
• Cockpit cushions = Romo Akiti outdoor basil - ' Basics book' Nikoya
• Logo on the 2 x aft hulls
• Nonslip aggregate anti slip on companionway step edges
