SWAN 48-216
EXTRA SPECIFICATIONS

Dimensions
LOA 14.78 m 48.49 ft
LWL 13.88 m 45.53 ft
Beam max 4.59 m 15.06 ft
Draught (light) 2.40 m 7.87 ft
Displacement (light) 15,000 kg 33,070 lbs
Ballast, standard keel 5,200 kg 11,465 lbs
Engine Volvo D2-75 Saildrive 55 kW 75 Hp
Rig and sail dimensions
IG 20.80 m 68.24 ft
J 5.66 m 18.57 ft
P 19.90 m 65.29 ft
E 6.60 m 21.65 ft
TPS 6.95 m 22.80 ft
Sail areas
Fore triangle 58.9 m2 633 sq.ft
Main sail 77.1 m2 830 sq.ft
Jib 62.5 m2 673 sq.ft
Gennaker 216.7 m2 2333 sq.ft
Tank capacity
Fuel 360 I 95.10 Usg
Water 500 I 132 Usg
Hot water 40 I 10.60 Usg
Holding tanks 1001 26.40 USg
Battery & power sources
Service battery, AGM 24 V 230 Ah
Shore power 230 V 32 A 50 Hz
Battery charger 70 A
Naval Architect
Germ?n Frers

SWAN 48-216
EXTRA SPECIFICATIONS

HULL

Hull finish
Hull colour light colour gelcoat, Atlas Natural Grey CAS4180.
Hull stripes to be standard white RAL 9016.
Colour of hull stripes, gelcoat, other than standard blue, from Nautor's standard selection.
JOTUN bottom paint, rolled 4 layers epoxy primer and 2 layers antifouling. Colour black.
Hull windows
Additional hull windows, 1 pair, in owner's cabin with manually operated blinds.
Additional hull windows, 1 pair, in aft cabins with manually operated blinds.
Boarding ladders
Carbonautica 2,3 m white painted GRP foldable gangway with light or dark grey antislint.
Width 370 mm. Including single pin deck fitting, black painted aluminium stanchions, trapeze
system and padded bag. Additional weight 11 kg.
Dinghy garage
Dinghy garage.

DECK
Deck finish
Coaming stripe on deck in Atlas Natural Grey CAS4180.
Teak woodwork
Teak on coamings, 6 mm, in way of winches. Additional weight 7 kg.
Winches & windlasses
Electrical winches, 1 pair, Harken 60.2 STEA instead of standard Harken 60.2 STA. Additional
weight 47 kg.

SWAN 48-216
EXTRA SPECIFICATIONS

Sail handling systems
Lifeline gates on each side amidships.
Self tacking jib system. Additional weight 20 kg.
Deck fittings
Seasmart B240X folding stainless steel cleats instead of standard fixed stainless steel cleats.
Additional weight 7 kg.
Outboard bracket on pushpit.
Cockpits
Locker in cockpit table for small items, including USB charger socket. Additional weight 6 kg.
Canvas work
Bimini over forward end of cockpit, frame divided from easy stowage, Sunbrella material, colour
from Nautor's standard selection.
Helmsman bimini, in Sunbrella material, colour from Nautor's standard selection.
Sun awning, in Sunbrella material, colour from Nautor's standard selection.
Cockpit cushions with backrests forward of steering wheels, Sunbrella material, colour from
Nautor's standard selection.
Canvas covers for steering wheels and pedestals, 2 pcs, in Sunbrella material, colour Cadet
Grey 5530.
Outside protection canvas in Sunbrella Cadet Grey 5530.
Cockpit cushions in Sunbrella Silver 5035 with piping in Cadet Grey 5530.
Piping for cockpit cushions.

INTERIOR
Interior general
Mood 1. Swan Soul
- Bulkheads: Oak, varnished, satin finish
- Furniture: Oak, varnished, satin finish
- Floorboards: Oak with light stripes, satin varnish Fabrics from Nautor selection. Leathers to
be quoted separately.
Upholstery according to Mood 2 renderings:
Saloon sofas:
- Caleido Sky Blue 3582 with piping Caleido White 10995.
Dining chairs:

SWAN 48-216
EXTRA SPECIFICATIONS

- Casual Gold 27 Throwpillows:
Casual Gold 27 with white stripes All leather details Whiskey SILK 0551.
Piping for saloon sofas and seats starboard. Fabric to be selected from Swan 48 Mood
collections.
Leather pockets in saloon, 3 pcs and forward cabin 4 pcs. With decorative stitching. Leather to
Whiskey SILK 0551.
Leather wrapping for overhead and main companionway handrails in saloon. With decorative
stitching. Leather to be Whiskey SILK 0551.
Leather wrapping for mast in saloon. With decorative stitching. Leather to be Whiskey SILK
0551.
Throwpillows 35x55cm in fabric matching saloon sofa, with white stripes, totally 11 pcs.
Fabric to be Casula GOLD27 with white stripes.
Aft cabins
Twin beds in aft cabin starboard. Additional fill-in part to convert into double bed.
Additional door from aft starboard cabin to aft toilet.
Saloon
Saloon table with adjustable height, electrically operated ?400mm instead of standard fixed
table. Cushions on table top, matching sofa cushions. Fabric to be specified.
Navigation area
Navigation desk with adjustable height, manually operated up or down position, instead of
standard fixed desk. Seat and backrest cushion on table top, matching sofa cushions. Fabric
to be specified.

___________________________________________________________________________
______________________________________________________________________

ENGINE AND HYDRAULICS

Thrusters
Bow thruster, Side-Power SRV100-24IP DC powered, swing type.
Powered by a 24V/75Ah battery. Battery charging from service battery by a 24V 16A DC
battery charger, Thruster is controlled by a joystick unit located on starboard pedestal.
Additional weight 137 kg.
___________________________________________________________________________
______________________________________________________________________

SWAN 48-216
EXTRA SPECIFICATIONS

PLUMBING AND VENTILATION
Fresh water system
Schenker Smart 100 Digital modular, 24VDC with a capacity of 100L/h, 2400L/day. The
watermaker is provided with dual pre-filters and fresh water flush. Additional weight 71 kg.
Black water system
Jabsco Quiet Flush [37045-3094] 24V DC toilet with electrical fresh water flush, 1 pee, in
forward toilet, instead of Jabsco 'Twist'n'Lock' [29090-5000] manual toilet, 1 pee.
Jabsco Quiet Flush [37045-3094] 24V DC toilet with electrical fresh water flush, 1 pee, in aft
toilet, instead of Jabsco 'Twist'n'Lock' [29090-5000] manual toilet, 1 pee.
Climate control
Air conditioning system.
Webasto Blue Cool S-Series self-contained unit installed to serve following:
-saloon 16.000 BTU/h
Power supply 230V AC single phase 50/60Hz Also included: cabin control panel with display
for the unit, seawater circuit with pump for cooling-off the unit, seawater intake with strainer,
thermally insulated ducting and air grilles.
Heating mode in reversed cycle.
NOTE: Diesel generator needed to run the air conditioning system off dock.
Webasto AirTop Diesel Heater System.
AirTop EVO 40, 4kW heater installed on port side in lazarette. Hot air ducted along port hull
side having branches and outlets into following:
- port aft cabin, galley, saloon, fwd toilet and owner's cabin.
AirTop 2000 STC, 2kW heater installed on starboard side in the lazarette. Hot air ducted along
stbd hull side having branches and outlets into following:
- stbd aft cabin, aft toilet, wet locker and the saloon. Both heaters have their own remote
sensors for room temperature in the saloon and MultiControls (panel with dispLAy) above the
main panel in the saloon.
Heater power supply 24V DC.

___________________________________________________________________________
______________________________________________________________________

ELECTRICAL
DC-system
Battery parallel switch for engine and generator batteries.
Service battery upgrade to a Lithium-Ion Victron Smart LiFeP04 Battery 25,6V 400Ah/3,3h
instead of std 24V 230Ah/20h Gel. Included in the installation is also a Victron BMV 712 Smart
battery monitor.
The battery is located inside hanging locker, in owners cabin.

SWAN 48-216
EXTRA SPECIFICATIONS

Additional weight 6 kg.
Engine and generator DC
Diesel generator M-GV8 PICCOLO K 230V / 50Hz Ungrounded, 8kVA (6kW) continuous
230V, installed in the engine room. Incl. Touch panel screen full color 5". Exhaust system for
generator to be installed.
Fuel system and sea water system to be modified to suit generator installation. Electrical
system to be modified to work together with generator. Starter battery charged by an
additional 12V, 5A charger, supplied by the 230 V system. Additional weight 251 kg.

___________________________________________________________________________
______________________________________________________________________

ELECTRONICS
Sailing instruments
B&G Triton base package , including:
- B&G Triton2 4.1" digital displays in the cockpit, 2 pcs.
- B&G Wind sensor WS310 mounted at mast head, 1 pee.
- DST800 combined speed, depth and temperature sensor, 1 pee.
- B&G Precision-9 compass, 1 pee.
- B&G ZG100 GPS antenna, on the port pushpit lower rail, 1 pee.
- B&G NAIS-500 AIS transponder including NSPL-500 VHF antenna splitter and GPS-500
GPS antenna. System is connected to Zeus and VHF antenna. GPS antenna is positioned on
pushpit.
- B&G V90S VHF radio at the chart table, 1 pee.
- B&G H50 VHF wireless handset positioned in the cockpit, 1 pee.
- AC Marine CX4 VHF antenna, mounted at the mast head, 1 pee.
- B&G NEP-2 network expansion port, located at chart table ,1 pee.
B&G Triton/H5000 20/20 HV displays, 3 pcs, located on mast bracket. Selden mast bracket
included.
Navigation systems
B&G HAL024 compact 24-inch dome radar antenna integrated with the B&G Zeus2 navigation
system. Including radar bracket. Additional weight 12 kg.
B&G Zeus312 inch multifunction displays, one on each pedestal in cockpit. Larger pedestals
included.
Entertainment systems
Marine stereo system Fusion MS-RA770 (AM/FM, WiFi streaming, optical in, USB, Bluetooth)
and ceiling speakers B&W CCM-362 one pair in saloon. Connected to B&G NMEA2000 bus
which allows control from MFDs. Additional weight 10 kg.

SWAN 48-216
EXTRA SPECIFICATIONS

Cockpit speakers one pair, Fusion MS-FR6021, connected to saloon stereo unit.
Autopilot systems
B&G autopilot for B&G Triton system. Autopilot controller located on port pedestal.

___________________________________________________________________________
______________________________________________________________________
RIG
ONESAILS
? Fullbatten in Boom Furling Mainsail
? Furling non overlapped Jib with vertical battens
? Staysail: Jib for inner forestay
? Furling Code 065 tight reaching sail, the most upwind capable of the asymmetrics Luff
is as straight as possible, and the sail is flatter than other spinnakers Fitted for roller
furling Furling cable included
? FX+4500
? A1.5: asymmetrical spinnaker medium wind runner (max area) medium nylon
construction
? SpiEx Snuffer

Mast
Upgrade of hydraulic system, backstay and boom kick instead of standard, in conjunction with
two function hydraulic pump in cockpit on port side.
Booms and poles
Upgrade from standard Selden aluminium boom to furlerboom GRP T20 manual. Only in
conjunction with standard aluminium mast. In conjunction with item code 8010669 upgrade of
hydraulic system.
Running rigging
2:1 Main halyard.
Staysail rope pack including sheet and 2:1 halyard with schackle block.

___________________________________________________________________________
______________________________________________________________________

SWAN 48-216
EXTRA SPECIFICATIONS

Anchoring and mooring
Galvanized anchor chain 80 m instead of standard 50 m. Additional weight 65 kg.
