The Company offers the details of this vessel in good faith but cannot guarantee or warrant the accuracy of this information nor warrant the condition of the vessel. A buyer should instruct his agents, or his surveyors, to investigate such details as the buyer desires validated. This vessel is offered subject to prior sale, price change, or withdrawal without notice.

Builder: Yontech Shipyard, Istanbul, Turkey
Year: 2018
Type: Cruising Sloop Yacht
Naval Architect: Taka Yat (Osman Tanju Kalaycıoglu)
Exterior Stylist: Osman Tanju Kalaycıoglu
Interior Designer: Örs Design
Construction: Strip plank + cold-molded Acajou epoxy hull, carbon composite hardtop, teak decks
Classification: RINA C+HULL@ MACH Y UNRESTRICTED NAVIGATION

Length Overall (LOA): 26.00 m
Length Waterline (LWL): 24.00 m
Beam: 6.20 m
Draft: 3.20 m
Gross Tonnage: 71
Displacement (full): 70 t
Ballast: 16 t
Cruising Speed: 8 knots (at 1,200 rpm)
Max Speed: 11.5 knots
Range: 800 nm
Fuel Capacity: 1,900 litres
Fuel Day Tank: 70 litres
Fresh Water: 2,000 litres
Grey Water: 1,400 litres (2x700)
Black Water: 700 litres

Air Draft: 33 m
Main Sail (Full-Batten): 167 m²
Blade Jib (Self-Tracking): 145 m²
Staysail: 66 m²
A-3 (Optional): 400 m²
Mast & Boom: Aluminium (painted/deep V)
Standing Rigging: Nitronic rod (ABS)
Running Rigging: DYNEEMA
Furlers: Reckmann RF90-3 (Headsail & Staysail)
Rigging Hydraulics: BAMAR
Sheet Trimming: Hydraulic Cylinders

Machinery

Main Engine: Cummins QSL9 - 330 HP @ 1800 rpm
Gearbox: ZF 360A (2.192:1)
Propulsion: Duplex stainless shaft, 4-bladed Brunton Varifold Ø750 mm
Fuel Consumption: ~17 L/h at 8 knots
Fuel Filters: Racor
Electrical & Auxiliary Systems


Generators:

1 x 6 kW Northern Lights (220V, 50Hz)
5 kW (220V 1PH, 50Hz)

Power Systems:

Shore Power: 380V / 220V 3PH 50Hz
DC System: 24V
Battery Banks: Service, Navigation, Starting (GEL, MASTERVOLT)
Solar Panels: 10 units on hardtop
Chargers: 2 x 100A
Inverters: 2 x AC MASTER 24/2500 (MASTERVOLT)

Steering: Manual (Lewmar), autopilot
Rudder: Carbon-epoxy sandwich spade with Jefa bearings
Bow Thruster: Lewmar 20hp Side-Power SP240/300TC-24-48

Pumps:
2 x Electric fire/bilge (engine room + bow)
1 x Emergency fire pump
Boiler: 2 x 1.5kW, 75L
Watermaker: Aqua Whisper 1400-2 (220 L/h)
Fresh Water Pumps: 2 x Whale (24V DC + 220V AC)
Toilets: Tecma electric freshwater
Air Conditioning: Webasto (min 72,000 BTU)
Keel: ST42 steel fin with lead bulb

Windlass: Lewmar V6 (2500 kW)
Auto Anchor: AA560 Maxwell

Winches:
2 x Lewmar 88/3 HST
2 x Lewmar 77/3 HST
Ground Tackle:
100 kg ULTRA 316 SS plough anchor
12 mm SS Chain (165m)
Spare: Ultra 21kg + 5m chain + 150m rope
Windows: Tempered, laminated solar-reflecting
Stanchions: 316L SS with gateways
Swim Ladder: Custom mountable
Passerelle: Hydraulic
Deck Tables: 4x, up-down adjustable
Portlights: Lewmar SS opening (aft cabins)

Compasses: 2 x Garmin 6" magnetic
Autopilot: Garmin GNX 120 XL
Echo Sounder: Panoptix PS-51 (thru-hull)
Radar: Garmin GMR 24xHD
GPS: 2 x GPS 19x NMEA 2000
Chart Plotters: Garmin GPSMAP 7416 (2 x helm, 1 x salon)
Displays: 6 x MI 20 Marine
Wind Instruments: Garmin
AIS: 1 x TB CS
VHF: 4 total
Loud Hailer: GARMIN

Life Rafts: 2 x 8-man (in fiberglass containers)
Firefighting:
1 x 15 kg FM-200 (engine room)
Portable extinguishers throughout
Seawater firefighting system
Alarms & Monitoring:
Central system (Concilium)
Substations in crew mess & captain's cabin
Fire alarms, float switches

Galley:
Bosch commercial cooker (4 hobs)
Bosch oven
Bosch dishwasher
Icemaker

Refrigeration:
Bosch 50L (Galley)
Bosch 300L (Salon)
Freezer (Top loading, lazarette)

Laundry:
1 x Bosch Professional washer
1 x Bosch Professional dryer
