2015 VOYAGE 520 SPECIFICATIONS

PRINCIPAL CHARACTERISTICS

Designer: VOYAGE yachts

Overall Length: 15.8 m 51.9 ft

Waterline Length: 14.4 m 47.1 ft

Beam: 8.3 m 27.1 ft

Draft: 1.20 m 3.9 ft

Mast Height off DWL: 20.80 m 68.22 ft

Displacement: 11176 kg 24640 lbs

Sail area: 125m2 1320 ft2

Water Capacity: 800 l 210 US Gal

Fuel Capacity: 500 l 132 US Gal

2 x Motors: 56 Hp YANMAR

Berths: 10

HULL DECK AND BULKHEADS

• Antifouling over epoxy based osmosis barrier

• Closed cell PVC foam core, vacuum bonded for stiffness, strength and minimal weight

• Forward water tight compartments with horizontal bulkheads

• Hand laid-up GRP construction using multi layers of Quadraxial glass roving, isophthalic and orthophthalic polyester resin and other high end materials

• Low aspect reinforced keels

• Marine ply and balsa core on critical structure bulkheads for added strength and stiffness

• Reinforced fitting areas for cleats and chain plates

• Skeg supported rudders

DECK FITTINGS:

STAINLESS STEEL, Grade 316

• Bow pulpits with teak bow seats

• Double guard wires with gates

• Grab rails on coach roof

• Stanchions and stanchion bases

• Stern pushpits with brackets for life ring buoys and overboard lights

• Swim ladder Port & Starboard

• Water stays attachment points for bow sprit

DECK EQUIPMENT

• Aluminium mooring cleats: 8

• ANDERSEN 46ST Secondary winches: 2

• ANDERSEN 52ST Primary winches: 2

• 1 x 52ST Primary winch upgraded to electric

• HARKEN Black Magic blocks

• HARKEN tracks and cars

• QUICK Electric windlass with remote control at helm

• SPINLOCK jammers

• Teak walkway between trampolines

• Webbing trampolines

PLUMBING:

• Automatic electric bilge pumps with alarms: 4

• Black water systems and holding tanks: 2

• Calorifiers 40 liters each (hot water system): 2

• Grey water systems: 5

• Manual bilge pumps: 2

• Pressurized Hot and cold deck shower Port & Starboard

• Self draining cockpit

• Tank tender gauges

• Deck wash system with faucets in aft locker and chain locker, with salt and fresh water supply

• 110V, 800 gpd water maker

SAFETY EQUIPMENT:

• Basic safety equipment including: flares, life jackets, first aid kit, life rings, smoke alarms and propane gas detection system

HATCHES AND WINDOWS:

• Anodised aluminium framed sliding door with safety glass

• GRP locker lids in cockpit: 6

• LEWMAR hatches: 15

• LEWMAR port lights: 10

• Reflective laminated safety glass windows: 8

• Ventilation hatch with teak grid

RIGGING:

• 7/8th fractional rig

• Anodised aluminium mast, boom, cross beam and double compression posts

• Colour coded sheets and control lines

• Double purchase main halyard

• Single purchase dedicated dinghy halyard

• Flag halyards

• Luff pendants: 2

• Mast supported by triple spreaders, intermediate and cap shrouds, forestay and inner forestay

• Navigation lights and VHF antenna

• PROFURL Genoa roller furler

• Reefing lines: 2

• Telescopic boom derrick for hauling dinghy

SAILS:

• HARKEN Battcar system for Mainsail

• Mainsail Stowage Pack with lazy jacks

• QUANTUM Fully battened main with large roach, 3 reef points, 11,9 oz high modulus cross cut Dacron with 2 ply leech

• QUANTUM Furling Genoa with foam luff and UV cover, 8,3 oz high modulus cross cut Dacron

COCKPIT/AFT DECK:

• Cockpit open aft and on single level with dive platform

• Cockpit table

• Dingy stowage supports and BBQ mounting point

• Propane supply for BBQ grill with quick connect attachment point for supply line

• Dive equipment and dive tank lockers: 2

• Double helmsman's seat

• Hard top Bimini with spray dodger and aft roll-away privacy / sun screen

• Sheet pouches: 2

• Steering console including

• Storage lockers: 6

• Instrument console

• Stainless steel steering wheel

• Teak dive platform and dinghy storage platform

• Teak grating at saloon sliding door

• Traveler arch

• Utility pouch: 1

• Deck wash system with faucet in aft locker with salt & fresh water supply

ACCOMMODATION:

MAIN SALOON

• Acrylic work surfaces

• IZIT leather upholstered settee

• Bar with seating for 3

• Coffee table

• Modules in moulded GRP

• Standing height throughout 1,9m

• Storage in seating modules

• Flooring in hard wearing Vinyl

• Air conditioning throughout

• 12V fans for air circulation

GALLEY:

• Acrylic work surfaces with stainless steel rails and fiddles

• Dedicated outlet for microwave oven

• Flooring in hard wearing Vinyl

• Gourmet Stainless Steel propane oven with rotisserie

• Large recessed drip tray

• Modules in moulded GRP

• Pressurized hot and cold water

• Propane hob burners: 4

• Stainless Steel sinks: 2

• Stainless steel waste chute with cover

• VITRIFRIGO Front opening refrigerator, 12V air cooled

• Molded top opening freezers, recessed into galley counter, 12V air cooled x 2

• U-Line ice maker

• Air conditioning throughout

• 12V fans for air circulation

FORWARD AND AFT CABINS:

• Air conditioning throughout

• 12V fans for air circulation

• Cabin and reading lights

• En Suite Heads with electric JABSCO toilet, shower, hand basin and vanity cabinet with mirror

• Hanging and storage cupboards

• Laundry locker with upholstered cover

• Modules in moulded GRP

• Queen size bunk with split mattresses

• Stainless steel towel rail

• Flooring in hard wearing Vinyl

CREW CABIN

• Air conditioning throughout

• 12V fans for air circulation

• Double mattress

• Lights

• Storage locker

DAY HEAD

• Moulded GRP heads with JABSCO electric toilet, shower, hand basin and vanity cabinet with mirror

• Stainless steel towel rail

NAVIGATION CENTRE:

• Access panels to electrical installation and systems

• Chart table with recessed chart stowage

• Instrument console

• Navigation seat

• 22" flat screen tv

• FUSION AV600G sound system with 3 x speaker zones: salon/galley, aft cockpit, lower spreaders for sound supply to foredeck

INSTRUMENTATION:

• Compass

• ICOM M-402 VHF Radio

• RAYMARINE ST60 Tridata and Wind

• RAYMARINE ST6002 Autopilot with WHITLOCK rotary drive

• RAYMARINE Raychart C95 Chart Plotter

• Remote control for windlass operation

ELECTRICS:

• AC shore cable socket

• AMPLE POWER Alternators, additional, with Smart Multi stage regulators with double belts 120A each: 2

• Battery isolator switches

• Battery management system

• Ceiling lights

• Circuit breaker panel

• Cockpit lights

• Deck light

• Spreader lights

• Underwater lights

• Engine start batteries (12V) @ 65 AH: 2

• Interior AC outlets: 4 in saloon, 1 in each cabin

• Lazarette and engine compartment lights

• Mast top and lower navigation lights

• Ships load battery banks (12V) gel - 400AH x 2 (800AH)

• 6kW NORTHERN LIGHTS generator

• 4 x 50W flush mount, non-skid solar panels

ENGINE EQUIPMENT:

• Alternators 55A: 2

• Fixed blade propellers with two blades: 2

• High pressure fuel line

• Instrument panels with engine hour meters: 2

• Sound insulation

• YANMAR 56 HP diesel engines with sail drive legs, fresh water cooled: 2

MOORING GEAR AND GROUND TACKLE:

• QUICK Electric windlass with remote control at helm

• Anchor bridle with thimbles for anchoring

• Anchor chain lead internally through compression post

• Anchor chain, 200' galvanized and 150' nylon anchor rode

• DELTA anchor, 40kg

• GUARDIAN 55 Secondary anchor with 10' chain, 233' rope, and dedicated cleat on forward crossbeam

• Dock lines and fenders

• Two anchor rollers, one with tipper

DINGHY

• 12' AB rigid inflatable tender with 15hp 2 stroke YAMAHA outboard

The Company offers the details of this vessel in good faith but cannot guarantee or warrant the accuracy of this information nor warrant the condition of the vessel. A buyer should instruct his agents, or his surveyors, to investigate such details as the buyer desires validated. This vessel is offered subject to prior sale, price change, or withdrawal without notice.
