• Hull made from composite, Roving 71 glass fibre + glass flakes against osmosis / isophthalic resin, monolithic laminate, laid up by hand (application / coating /
  air removal) in lengthwise and transverse layers with a two thirds overlap.
• Frame structure in polyurethane omega-foam and plywood, laminated to the hull, as is all the joinery structure (bulkheads, furniture units, lockers, etc.)
• This system guarantees the highest rigidity of the whole unit and optimises load spread. Compression forces from the masts / rigging are compensated by a?structure of support pillars for the masts and chain plate tie-rods laminated to the hull for the rigging.
• The bulkheads are glued and laminated with the deck. 4 of them are watertight bulkheads with isolation valves.
• Composite Roving 71 glass fiber / isophtalic resin and balsa sandwich deck moulded by the same process as the hull (the deck is glued and laminated to the hull?and the bulkheads).
• The fore and aft bridge, foredeck and quarter deck are made from ?Amel teak", moulded into the deck.
• Self-bailing cockpit (2 scuppers, 100 mm diameter)
• Cast iron ballast fixed to the hull / keel by stainless steel bolts, sealing by Epoxy treatment.
• Monolithic laminate rudder with skeg made from plain composite, moulded in one piece with the hull. The rudder is mounted at 3 points, the rudder trunk is
  laminated and the intermediate fitting and socket are stainless steel, bolted. Stainless steel rudder stock, 60 mm in diameter.

• Stainless steel bow fitting for 2 anchors. Fresh water outlet on the deck.
• Electric windlass controlled from the cockpit, stainless steel B?gel (Wasi) 30kg anchor, 100m of 10mm galvanised chain (2nd electric windlass available as an?option).
• Stainless steel pulpit, pushpit and side rails (opening in the pushpit for easy access to quay or pontoon). Stainless steel guard line.
• LED navigation lights.
• 8 stainless steel mooring cleats.
• Bracket for outboard engine in aft locker
• Stainless steel chain plates.
• Sheet traveller tracks with tidy travellers
• Set of pulleys throughout
• All the controls (manual and electric) of sheets and mainsail tackle are run to the?cockpit.
• 2 electric genoa sheet winches.
• 2 stay sail sheet winches.
• 1 electric mainsheet winch.
• 1 mizzen sail sheet winch.
• 2 manual main mast winches.
• 1 manual mizzen mast winch.
• Halyard downhauls : 2 on the main and 1 on the mizzen mast.
• 4 halyard clutches (including one double) and 1 on main mast (staysail option).
• Manual removable gangway
• 12 hatches ; 6 opening portlights.
• On deck, 4 large lockers:
• At the foredeck : a large locker with easy access to the bow
  thruster and chain lockers, a wide space for fenders, mooring lines
  and extra sails.
• To portside, next to the cockpit : a locker for various equipments (oil
  tank for the outboard engine, cleansing products, hosepipes, etc.)
• Right by this locker : a second locker with 2 gas cylinders fitted with
  1 safety pressure valve and an electric valve. The whole locker
  breathes to the fresh air.
• On the aft deck : a large locker for a possible dinghy, outboard
  engine, diving equipment, fenders and others.

• Large, comfortable and reassuring cockpit.
• 1 helmsman?s station in the wheelhouse with a leather covered stainless steel wheel. The wheel steering is mechanical.
• Console in front of the wheel for the electronics, together with all the other controls (windlass, furling gear, thruster, etc).
• Very comfortable composite helmsman?s seat with leather seat and back.
• Adjustable teak and laminate cockpit table.
• Large locker with light in the cockpit on portside + locker at the mizzen mast foot on portside

Saloon

• It is very bright and spacious. It provides an excellent view of the outside from its 4 opening hatches and 4 large hull portlights.
• Direct and indirect lighting (mainly LED).
• Numerous electrical sockets.
• Large sliding table with extension, for 8 people, with very comfortable U shaped seat. Close storage for dishes.
• Saloon part: 1 very comfortable sofa with a wine / spirit cabinet and storage for glasses.
• Audio system: radio-CD-MP3 with BOSE acoustics.
• Forward Owner's Cabin
• Closed by a watertight door. It covers the full width of the hull. It is vast, very light and well ventilated thanks to 3 deck hatches and 2 hull portlights. LED lighting by?ceiling lights, wall lamps and reading lamps (mainly LED).
• Central 1.60m double bed, slat base and high density foam mattress. Very large storage space under the bed with top access.
• Cabinets, drawers, and a large hanging locker for optimum ease of storage.
• Desk unit/dressing table to starboard with swivelling seat, mirror and 220V sockets.

Heads compartment

• Spacious shower, floor grating and sliding door, mixing tap. Handrail in the shower, storage and lights.
• Lighting by deck hatch and ceiling lights.
• Storage unit with deep flush washbasin and mixer tap.
• Cabinets, towel rail, clothes hooks, toilet paper holder and mirror.
• Electric vacuum marine toilet (fresh water) with black water tank.

• Situated to the left of the companionway, it is very large and is a major feature of the life on board. A large opening portlight gives a view of the outside whilst doing?the cooking.
• It is naturally very light, great attention has been paid to the lighting and ventilation which are excellent.
• It comprises 2 large working surfaces made of moulded Corian with surround
• 2-basin stainless steel sink with mixer tap and hand shower.
• A combination of low units, drawers and upper cabinets.
• A gimbal-mounted 3-burner stove/oven, with potholders.
• Electric extractor hood with filter
• Stainless steel microwave oven, 220V
• 150 litre refrigerator and 150 litre freezer.
• Several 220V sockets.
• Fresh water capacity: 1 x 800 litre tank with access through hatches.
• Partitioned wastewater tank (capacity: approximately 60 litres), with 2 sewage pumps

• Very spacious watertight engine room, with very efficient sound insulation.
• The?engine and all the heavy equipment (generator set) are centred and positioned?very low.
• High density insulating foam and inside coating with high acoustic performance.
• Several lighting points, 220V and 24V sockets.
• Access: from the cockpit, full opening of the cockpit bottom assisted by gas
  struts.
• Volvo engine, 5-cylinder, low speed diesel engine, 110HP, hydraulic gearbox with?shaft brake. Electric throttle. AMEL angle transmission.
• Fixed 3-blade propeller (folding propeller available as an option).
• Diesel fuel capacity: 900 litres.
• Double diesel fuel filter with 3-way tap.
• 24V fans: 1 extractor for the engine compartment, 1 extractor for the battery
  compartment.
• Onan 3-cylinder generator, 1500 rpm, 7,5 kW.
• Retractable electric bow thruster, 11HP.
• Fresh water pump, hot water tank (50 litres)

• 24V and 220V distribution boards with ammeters?and voltmeters.
• 12V circuit for engine and generator.
• 24V, 600 Amp/h service circuit.
• 220V circuit with cable and pontoon connector at?the aft, and 220V/24V, 100 Amp charger.
• 24V interior lighting (mostly LED).
• 12V, 24V and 220V sockets

• Furuno FR1835 radar.
• Furuno GP33 and GP330 GPS.
• B & G Hydra 5000 including: 1 GFD at chart?table, 1 GFD in cockpit.
• Garmin VHF at chart table
• Hydraulic Furuno Navpilot 711 automatic pilot.

• The Amel 55 is rigged as a ketch.
• "AMEL" main and mizzen masts. Both masts are designed and entirely
  manufactured by AMEL. The finish is a 2-component polyurethane paint. 2
  sets of spreaders on the main mast and 1 on the mizzen. AMEL 24V
  electric roller reefing system with manual release on the main mast.
• AMEL electric roller reefing system on the mizzen with manual release.
• LED deck lights on the main and mizzen masts.
• Mooring and masthead lights (LED).
• Single strand stainless steel standing rigging .
• Vectran and Dyneema halyards.
• Purpose built AMEL booms, finished in polyurethane paint.
• Down-haul on the main boom.
• Automatic toping lift on mizzen boom.
• Reckman electric genoa furling gear.
• External halyard on main mast.

1 x VOLVO PENTA D3 110hp
