Solid fiberglass hull, hand laminated, using knitted and stitched biaxial fabrics in conjunction with mat and woven roving, Vinylester and isophthalic resin in hull lay-up. Isophthalic gelcoat applied on all exterior fiberglass surfaces. A matrix of longitudinal and transverse foam cored stringers in the lower hull and hull sides provide maximum hull stiffness.

Internal lead ballast glassed into a modified fin keel. Balanced skeg mounted rudder, with internal stainless steel rudder post and integral stainless steel reinforcement.

The deck structure is a composite construction using closed cell foam coring. All deck hardware is reinforced using high density foam core. All deck hardware is through bolted using stainless steel backing plates.

• Lighthouse 1501 electric windlass with stainless steel release
• Bow pulpit with double bow rollers and teak seat
• Rocna Vulcan 55 lbs. primary anchor (new 2023) with 200 feet of 5/16″ HT chain rode
• Delta 45 lbs. secondary anchor with 150 feet of 5/16" HT chain rode and rope.
• Fortress FX-37 stern anchor with chain and rope rode in stern anchor locker
• Teak Cap rail with stainless steel striker
• Teak eyebrow
• Deck surrounded by double life lines. (new 2019)
• Stainless steel sector panel arch mounted on stern with dinghy lift blocks.
• Port and starboard aft teak seats
• Stern anchor with stern hawse and cleat
• Custom Teak companionway doors and heavy duty Lexan drop boards for use at sea
• Stainless boarding and swim ladder on stern
• (15) Stainless opening ports with safety glass and screens
• (5) Lewmar Offshore Series overhead hatches with Sunbrella covers
• (5) Halyards and pole topping lift
• Harken sail tracks with Harken blocks and cars
• Fresh or raw water deck wash down
• (2) 20-pound Aluminum propane tanks (serviced 2023) in fiberglass molded and vented propane locker
• (6) Fairleads with custom Aqualoy stainless steel rollers (Aqualoy is high quality shafting)
• (2) Bow cleats, (4) mid ship cleats and (2) aft cleats
• Hot and cold-water aft deck shower
• Adjustable dynema running backstays
• Edson outboard motor mount on starboard stern rail
• Outboard motor hoist
• Flag pole holder
• Quantum dark blue dodger, connector and bimini
• Emergency manual bilge pump
• (4) Dorade vents with stainless steel rail surrounds
• (2) Mast pulpits
• Hull Flag Blue Awlgrip
• Hull bottom scraped/sanded to gel coat, 2 coats epoxy, 3 coats (1 red, 2 black) Sherwin Williams Seaguard P30 (2023)
• Cabin top stainless-steel handrails

• Forespar In-Mast furling system. (Foil rebuilt, bearings serviced 2024)
• Forespar mast. (inspected 2024 - excellent condition no repairs necessary)
• Standing rigging (replaced 2019 - inspected 2024, excellent condition)
• Harken III furlers on forestay and cutter stay (serviced 2022)
• Harken staysail and yankee furling line blocks (new 2022)
• New outhaul car Harken 3096 (new 2024)
• Quantum main sail, Contender supercruise 10.4 100%, 468 sq.ft, with Rutgerson 100mm clew block, new 2022
• Quantum head sail, 115% Yankee, TriRadial Palma CL18P 100%, 523 sq.ft., New 2022
• Quantum stay sail, 65% Staysail, TriRadial Palma CL18P 100%, 209 sq.ft., New 2022
• (2) Harken 66.2, 2-speed, self-tailing primary winches
• Harken 44, 2-speed, self-tailing main sheet winch
• Harken 46, 2-speed, self-tailing utility winch (new 2023)
• Harken 50, 2-speed, self-tailing utility winch (new 2023)
• Electric Harken 40, 2-speed, self-tailing utility winch
• Harken 44 and 40, 2-speed, self-tailing halyard winches on mast
• Forespar Yacht rod/boom vang
• Spinnaker pole and gear with on-mast storage
• Inside boom preventer with control lead to cockpit.
• Split backstay

• Ritchie Powerdamp compass with light.
• Vetus Bow Thruster control head
• Raymarine Axiom-9 chartplotter and radar display in Nav Pod.
• Raymarine RD424HD 24-mile radar (dome mounted on mast)
• Raymarine p70s autopilot head (new 2024)
• Raymarine i50 depth indicator (new 2024)
• Raymarine i60 wind indicator (new 2024)
• Raymarine i50 speed indicator (new 2024)
• ICOM ICM-402 RAM VHF remote power microphone

From tender or dock you step aboard the Passport 470 Center Cockpit through either the port or starboard boarding gates and onto the wide side decks that offer excellent and safe maneuverability fore and aft. The foredeck can accommodate a 9' dinghy for off shore stowage and provides easy access to the windlass and twin bow rollers. The aft deck provides access to a large lazarette, stern arch for inshore dinghy stowage, outboard motor mount/lift, rail mounted life raft, and stern boarding ladder.

The cockpit has seating for a crowd with large settees both port and starboard and the helm seat offers excellent visibility and easy access to all engine controls and navigation tools. All lines for sail control lead to the cockpit making sailing by a couple an easy task. The cockpit is sun and weather protected by a dark blue bimini, dodger, connector, and side panels.

Through the companionway door you enter the main cabin. Extremely well thought out, the main cabin is spacious and light. Under the companionway steps is access into the clean engine compartment with easy access for checking daily or for major repairs.

​

Starboard and aft is the galley area which is large and offers exceptional space for the onboard chef. Plenty of counter top room for preparing most any gourmet meal. You can enter aft stateroom through the galley. The aft cabin is large with a centered queen size berth, ample cabinet, and drawer spaces and plenty of natural light and ventilation. Along the port side is access into the head compartment. You can also enter the head compartment down the port side companionway from the salon. The head offers two separate areas. First has the vanity and toilet and the forward is the separate shower stall. Privacy doors port and starboard keep the aft cabin private and quiet.

​

Aft of the salon to port is the navigation station with cabinet and desk storage. The seat faces forward and allows for excellent communication with guests in the salon. The salon is large with port side settee and outboard storage and cabinets, while to starboard is a unique settee that can be used as two separate chairs with the addition of the centered removable cocktail table or it can be used as a single settee or sea berth. Centered is a beautiful salon table with two tops. One for dining and one for a cocktail table. The table can be lowered. Further forward is the V-Berth with plenty of room for storage with cabinets and drawers. The V-Berth has a private head with a separate shower stall.

• Raymarine Axiom-9 chartplotter and radar display
• Raymarine ST-6001 Smart Pilot autopilot
• Raymarine ST-60+ Multi, depth and speed
• em-trak AIS (new 2022)
• ICOM ICM-402 VHF Radio
• (2) VDO gauges for fuel tank level
• (2) VDO gauges for water tank level

• Corian countertops with fiddles
• Double stainless steel sinks with separate fresh water and drinking water faucets.
• Nature Pure QC water filter (new 2024)
• Princess stainless steel propane stove and broiler with (3) stove top burners
• Stainless steel safety bar
• Stove stainless steel surround
• Trident propane gas control with solenoid
• Black and Decker microwave oven
• Frigoboat 12-volt top-loading and front-loading refrigerator (new compressor, keel cooler, condensor plates 2023)
• Frigoboat 12-volt top loading freezer (new compressor, keel cooler, condensor plates 2023)
• Built-in pull out trash bin
• Ample cabinet and drawer storage
• Ventilation fan

Excellent engine compartment access with 3-sided access under companionway steps and both side of the engine. The engine compartment features lead foam insulation for significant noise reduction.

• Yanmar 4JH80 80 hp marine diesel engine with 720 hours, (new 2016)
• Max-Prop 18-inch folding propeller.
• Spare fixed prop.
• Yanmar cockpit engine panel with RPM, engine temperature, oil pressure and alarms
• (2) Racor primary engine fuel filters
• Edson pedestal with steering wheel brake. Bearings serviced and steering cables/chain replaced with new 2023).
• Lewmar folding steering wheel (new 2022)
• Raymarine Type III Hydraulic Autopilot actuator, (Serviced 2023)
• Raymarine autopilot ACU 400 (new 2024)
• Raymarine autopilot sensor core EV-1 (new2024)
• Dual levers for engine and transmission controls
• Northern Lights 5kw generator with Racor filter (new 2023)
• Vetus 95kgf bow thruster
• Lighthouse 1501 Windlass
• Water Maker - Village Marine LWM 200, Pickled.
• Forward Head, Jabsco Quiet Flush, (new 2023)
• Aft Head, Air Head (new 2023)
• Engine exhaust blower 12V

• Main electrical panel is located at the navigation station.
• 12-volt DC and 120-volt AC power with power distribution panel and circuit breakers
• AC amp and volt meters
• DC amp and volt meters
• (2) 30-amp shore power cords with 50-amp splitter
• Samsung flat screen TV mounted on salon bulkhead
• 12-volt Ventilation fans
• 360 watt Solar panels
• Victron MPPT 100/30 with blue tooth monitoring
• D400 Wind generator (full service 2022)
• Shakespeare mast TV antenna
• Starlink high-speed wireless antenna and modem (installed 2024)
• (2) Battery selector switches
• Link 2000 battery monitor
• Victron Multiplus 3000 inverter with battery charger and blue tooth status monitoring (new 2023)
• (4) Group-D AGM 160 ah house batteries.
• (2) Group-31 AGM starter/thruster batteries (new 2023)
• Stainless steel cabin lights upgraded to LED (2023)
• Engine room and lazarette lighting
• (5) 12-volt Ventilation fans (new 2023)
• Mermaid self-contained reverse cycle marine air conditioning and heat unit, 16,000 BTU, located in salon.
• CTM self-contained reverse cycle marine air conditioning and heat unit, 10,000 BTU located in aft cabin (new 2023)
• SCAD TM1 forward head tank monitor (new 2023)
• 11-gallon, 110-volt Hot water heater with engine heat exchanger
• Weems and Plath clock and barometer

• ACR 406 MHz EPIRB
• Fire extinguishers
• Viking RescYou six man liferaft, L006U00741AME (new 2022)
• Life sling
• Emergency tiller

2024:

• Mast unstepped, inspected, main furler removed and rebuilt, mast head wind instruments replaced with new.
• Nature Pure QC water filter added at galley sink.
• Upgraded outhaul car to Harken 3096
• Raymarine instrument upgrade to STng backbone, new i50/i60 instruments, new ACU-400, and EV-1 sensor.
• Bow thruster rewired and isolation switch added.
• Raymarine Type III autopilot actuator, refurbished.
• Starlink Antennae and Modem added.
• Forward and aft head sink faucets replaced
•

2023:

• New Northern Lights Generator installed.
• Frigo Boat freezer and refrigerator systems replaced with new; including compressors, condensor plates, and keel coolers.
• Hull bottom scraped/sanded to gel coat, 2 coats epoxy, 3 coats (1 red, 2 black) Sherwin Williams Seaguard P30.
• Forward Head toilet replaced with Jabsco Quiet Flush and new head tank level monitor (SCAD TM1) added.
• Aft head toilet replaced with Air Head.
• Port companionway winch upgraded with full grounded backing plate to new Harken 50 2-speed self tailing.
• Port cockpit new Harken 46 2-speed self tailing winch added with full grounded backing plate for trimming headsail furler.
• Aluminum 20lb propane tanks (2) serviced and recertified.
• Raw Water Strainers on Generator and air conditioner pumps updated to Groco ARG-755 (3).
• New Rocna Vulcan anchor 55lb.
• Edson Steering Pedestal bearings and cables replaced.
• Cabin light halogen bulbs replaced with LED bulbs
• Cabin ventilation fans (5) replaced with new 12V Caframo fans.
• Aft AC unit upgraded to new quieter CFM 10,000 btu unit.
• Mastervolt AGM Type 31 batteries (2) replaced.
• Custom curtains in salon and aft cabin.
• Trash drawer upgraded to two bins.

2022:

• D400 Wind Generator refurbished.
• Main, Yankee, and Stay sails replaced with new. (Quantum Sails, Annapolis, MD)
• Harken Mk III furlers serviced, furling lines replaced, furling line blocks replaced with new Harken equipment.
• Custom seat covers replaced in salon.
• New Lewmar folding wheel.
• Bow rollers replaced.

2019:

• Standing rigging replaced.
• Lifelines replaced.
• Chain plates rebedded.

2016

• Yanmar 4JH80 engine (approx. 720 hours)
